Kyushu J7W1 Shinden Interceptor Fighter

By William Pearce

Masayoshi Tsuruno (also spelled Masaoki) was a member of the Imperial Japanese Navy’s (IJN) Aviation Research Department. Around 1940, Tsuruno first began to investigate designs of a pusher aircraft with a canard layout. Tsuruno’s research led him to believe that such a configuration would enable an aircraft to achieve a very high level of performance. In addition, the basic configuration could be easily adapted to turbojet power if such an engine became available.

Kyushu-J7W1-Shinden-left-rear

Kyushu J7W1 Shinden was an unorthodox fighter designed to intercept US bombers at high speed and high altitude. Although just two were completed, it was the only canard aircraft ordered into production during World War II. Exhaust from two cylinders flowed out the two ejector slits atop the engine cowling.

In early 1943, the IJN issued 18-Shi Otsu specification calling for a land-based fighter capable of intercepting enemy bombers. The aircraft should achieve 460 mph (740 km/h) at 28,543 ft (8,700 m), reach 26,247 ft (8,000 m) in 10.5 minutes, have a service ceiling of 39,370 ft (12,000 m), and carry four 30 mm cannons. Tsuruno worked up a design for such an aircraft and submitted it to the IJN. The IJN liked the design but was hesitant to move forward with the radical, untested configuration. Tsuruno was able to work with the First Naval Air Technical Depot (Dai-Ichi Kaigun Koku Gijitsusho) at Yokosuka to develop a proof of concept, designated MXY6.

The Yokosuka MXY6 was a glider of all wooden construction possessing a canard layout with fixed tricycle landing gear. The aircraft featured a foreplane with elevators mounted to its nose for pitch control. The swept wings were mounted to the rear fuselage, and each wing had a vertical stabilizer with a rudder mounted near its mid-point. Three of the gliders were built by Chigasaki Industry Ltd (Chigasaki Seizo KK). Piloted by Tsuruno, the MXY6’s first flight was made in January 1944. Later, one of the gliders was fitted with a 22 hp (16 kW) Nippon Hainenki Semi 11 [Ha-90] engine turning a wooden, fixed-pitch, two-blade propeller. The engine was not intended make the MXY6 fully operational under its own power, but it would enable the aircraft to sustain flight and prolong its glide. The MXY6’s flight tests indicated that Tsuruno’s design was sound. The aircraft handled well at low speeds and resisted stalling. Based on the positive preliminary tests of the MXY6, the IJN decided to proceed with Tsuruno’s 18-Shi Otsu design in February 1944. The aircraft would be built by the Kyushu Airplane Company (Kyushu Hikoki KK), and it was designated J7W1 Shinden (Magnificent Lightning).

Yokosuka_MXY6_Glider

One of the Yokosuka MXY6 gliders that survived to the end of the war and was found by US forces. The glider validated the basic configuration that was later applied to the J7W1.

Kyushu Airplane Company was founded in October 1943 as a subsidiary of the Watanabe Iron Works Ltd (Watanabe Tekkosho KK). Kyushu was selected as the manufacturer because it had both workers and production facilities that were available. Kyushu had no experience designing high-performance fighter aircraft, but the company would be aided by Tsuruno and the First Naval Air Technical Depot. An official order for the J7W1 was issued in June 1944, with the prototype’s first flight expected in January 1945.

The Kyushu J7W1 Shinden used the same layout as the MXY6, having a canard configuration with a swept, rear-mounted wing and tricycle undercarriage. The aircraft consisted of an aluminum airframe covered by aluminum panels, forming a monocoque structure. Depending on location, the panels were either flush riveted or spot welded in place. The control surfaces were skinned with aluminum. The foreplane had two spars and was mounted to the extreme nose of the aircraft at a one-degree angle of incidence. A leading-edge slat was deployed with the flaps. On the foreplane’s trailing edge was a two-section flap. The first section acted as a traditional flap that extended 26 degrees. The second section on the trailing edge acted as an elevator.

Mounted in the fuselage between the foreplanes were four 30 mm Type 5 cannons, each with 60 rounds per gun. Each cannon was 7 ft 2 in (2.19 m) long and weighed 154 lb (70 kg). The cannons were slightly staggered to allow for clearance of their respective feed belts and keep the fuselage as narrow as possible. A compartment under the cannons collected the spent shell casings because of concerns that they would strike the propeller if they were ejected from the aircraft. Two 7.9 mm machine guns with 75 rounds per gun were planned for the very front of the nose and could be used for either training or target ranging. As ranging guns, they would help ensure that the cannon shells hit the intended target and not waste the limited ammunition supply. No armament was fitted to the prototype, and ballast weight was used to simulate the cannons.

Kyushu-J7W1-Shinden-left

The wheels under the vertical stabilizers were added after the aircraft’s first flight attempt ended with bent propeller blades. Note the long landing gear’s relatively short wheel base.

Behind the cannons was the single-seat cockpit, which was covered by a rearward-sliding glazed canopy. The pilot was protected by 2.76 in (70 mm) of armored glass in the front windscreen and a .63 in (16 mm) bulkhead by the cannons. Passageways ran on both sides of the aircraft between the cockpit and outer skin. Flight controls, hydraulic lines, and wiring ran in these passageways, which were accessible via removable outer skin panels. Under and slightly behind the cockpit was a 106-gallon (400-L) self-sealing fuel tank made of .87 in (22 mm) thick rubber.

Directly behind the cockpit was a 44-gallon (165-L) oil tank, followed by a Mitsubishi [Ha-43] 42 (IJN designation MK9D) engine. The [Ha-43] was a two-row, 18-cylinder, air-cooled engine. The [Ha-43] 42 had two-stage supercharging, with the first stage made up by a pair of transversely-mounted centrifugal impellers, one on each side of the engine. The shaft of these impellers was joined to the engine by a continuously variable coupling. The output from each of the first stage impellers joined together as they fed the second stage, two-speed supercharger mounted to the rear of the engine and geared to the crankshaft. As installed in the J7W1, the engine produced 2,030 hp (1,514 kW) at 2,900 rpm with 9.7 psi (.67 bar) of boost for takeoff. Military power at 2,800 rpm and 5.8 psi (.40 bar) of boost was 1,850 hp (1,380 kW) at 6,562 ft (2,000 m) in low gear and 1,660 hp (1,238 kW) at 27,559 ft (8,400 m) in high gear.

Kyushu-J7W1-Shinden-front

The prototype was unarmed, but four 30 mm cannons, each capable of firing 500 rounds per minute, were to be mounted in the nose. The projectile from each 30 mm shell weighed 12.3 oz / 5,401 grains (350 g).

The engine was mounted in the center of the fuselage and atop the wingbox. An extension shaft approximately 29.5 in (750 mm) long extended back from the engine to a remote propeller reduction gear box. The extension shaft passed through an extended housing that was mounted between the engine and the propeller gear reduction. The gear reduction turned the propeller at .412 times crankshaft speed and also drove a 12-blade cooling fan that was 2 ft 11 in (900 mm) in diameter. A screen was placed in front of the fan to prevent any debris from exiting the rear of the aircraft and hitting either the fan or propeller. Mounted to the propeller shaft was a 11 ft 2 in (3.40 m) diameter, metal, six-blade, constant-speed, VDM (Vereinigte Deutsche Metallwerke)-type propeller built by Sumitomo Metal Industries Ltd, Propeller Division (Sumitomo Kinzoku Kogyo KK, Puropera Seizosho). The propeller had approximately 29 in (740 mm) of ground clearance with the aircraft resting on all of its landing gear. If bailing out of the aircraft was needed, the pilot could detonate an explosive cord that would sever the propeller and gear reduction.

Cooling air for the [Ha-43] engine was taken in via an oblique inlet mounted on each side of the fuselage just behind the cockpit. Flaps at the inlet’s opening were raised to decrease the flow of cooling air to the engine. Cooling air entered the inlets, passed through the fins on the engine’s cylinders, traveled along the outside of the extension shaft housing, passed through the cooling fan, and exited around the spinner or an outlet under the rear of the aircraft. Two intakes, one on each side of the aircraft, were mounted to the cooling inlet. These intakes ducted induction air through the cooling air duct and directly into the transversely mounted superchargers.

Kyushu-J7W1-Shinden-Ha-43-42-engine

The Mitsubishi [Ha-43] 42 engine installed in the J7W1 as seen post-war. The front of the aircraft is on the left. One of the two transversely-mounted, first-stage superchargers can be seen left of the engine. The oil cooler duct is in place and blocking the view of the extension shaft to the right of the engine. On the wing is the middle panel of the supercharger’s inlet scoop.

On each side of the fuselage directly behind the induction scoop was an inlet for an oil cooler. For each of the two oil coolers, after air passed through the cooler, it was mixed with the exhaust of four cylinders and ejected out a slit on the side of the fuselage just before the spinner. The ejector exhaust was used to help draw air through the oil coolers. The same philosophy applied to the exhaust from six cylinders on the bottom of the engine. These were ducted into an augmenter that helped draw cooling air through the cowling and out an outlet under the spinner. The exhaust from the remaining four cylinders, which were located on the top of the engine, exited via two outlets arranged atop the cowling to generate thrust.

The leading edge of the J7W1’s wing was swept back 20 degrees, and the trailing edge was swept back six degrees. The wings were mounted with no incidence angle. The inner wing from the wingbox to the rudder had 2.5 degrees of dihedral, and the outer wing from the rudder to the tip had zero dihedral. The structure of each wing was formed with three spars. The front spar ran along the wing’s leading edge. The center, main spar was swept back 14.5 degrees and ran in front of the main landing gear wells. A rear spar was swept forward 3.5 degrees and ran from the wingbox to just behind the main gear mount. A vertical stabilizer extended above and below the rear spar. The vertical stabilizer was mounted at approximately the midpoint of each wing and extended past the wing’s trailing edge. Initially, nothing was mounted under the vertical stabilizers, but a wheel was later added under each stabilizer to prevent propeller ground strikes. A rudder ran the entire 7 ft 3 in (2.20 m) height of each vertical stabilizer. Each wing housed a 53-gallon (200-L) fuel tank and a 20-gallon (75-L) anti-detonation fluid (water/methanol) tank for injection into the engine. Split flaps were positioned along the trailing edge of the wing between the vertical stabilizer and the fuselage. The flaps on the main wing extended 20 degrees. Two hardpoints under each outer wing could accommodate 66 or 132 lb (30 or 60 kg) bombs.

Kyushu-J7W1-Shinden-rear

Rear view of the J7W1 showing its six-blade propeller and the engine’s 12-blade cooling fan in the rear of the cowling. The exhaust augmenter outlet can be seen on the bottom of the cowling. Note the rudders extending the entire height of the vertical stabilizers.

When deployed, the legs of the main gear were angled forward more than the nose gear. This effectively extended the nose gear and caused the aircraft to sit five-degrees nose-high while on the ground. This stance minimized the rotation needed to achieve liftoff, which is very important in the pusher aircraft. The main gear was mounted forward of the vertical stabilizers. The swiveling but non-steerable nose gear retracted forward, and the main gear retracted inward. Gear retraction and extension were powered hydraulically. At approximately 5 ft 11 in (1.8 m) long, the landing gear was quite tall to allow clearance for the propeller. The gear had a fairly wide track of 15 ft (4.56 m), but the wheelbase was short at only 10 ft 2 in (3.11 m). The short wheelbase combined with the tall gear legs and the aircraft’s high center of gravity could have given the J7W1 undesirable ground handling characteristics.

The J7W1 had a 36 ft 5 in (11.11 m) wingspan, was 32 ft (9.76 m) long, and was 12 ft 10 in (3.92 m) tall. The aircraft had a top speed of 466 mph (750 km/h) at 28,543 ft (8,700 m), a cruising speed of 276 mph (444 km/h), and a stalling speed of 107 mph (172 km/h). The J7W1 could climb to 26,247 ft (8,000 m) in 10 minutes and 40 seconds and had a 39,370 ft (12,000 m) service ceiling. The aircraft had an empty weight of 7,639 lb (3,465 kg), a normal weight of 10,864 lb (4,928 kg), and a maximum weight of 11,526 lb (5,228 kg). Cruising at 9,843 ft (3,000 m) gave the J7W1 a 528-mile (850-km) range. The aircraft was stressed for a maximum speed of 575 mph (926 km/h) and 7 Gs.

Kyushu-J7W1-Shinden-front-left

The various ducts on the side of the J7W1 are illustrated in this image. The flaps to reduce cooling air can be seen just before the oblique inlet on the side of the aircraft. The smaller scoop that fed air into the supercharger is mounted to the outside of the cooling air inlet. The oil cooler inlet can be seen just behind the tapered fairing for the induction scoop.

While the prototype was still under construction, the IJN ordered the J7W1 into production in May 1944 to counter the imminent threat of American bombing raids with the Boeing B-29 Superfortress. Ultimately, the production schedule called for Kyushu to produce 30 aircraft per month, and the Nakajima Aircraft Company, Ltd (Nakajima Hikoki KK) would build 120 units per month. In June 1944, the United States Army Air Force began conducting bombing raids against Japan using the B-29. To intercept these bombers and disrupt these raids were the exact purposes for which the J7W1 was designed. In September 1944, a mockup of the J7W1 was inspected by the IJN, and wind tunnel tests of a scale model had yielded positive results.

The J7W1 was built at Kyushu’s Zasshonokuma Plant, near Fukuoka city. The airframe was nearing completion in January 1945, when the first flight was originally scheduled to be conducted. Bombing raids delayed delivery of the [Ha-43] 42 engine, which finally arrived in April. The J7W1 was finally completed on 10 June and was subsequently disassembled and moved to Mushiroda Airfield (now Fukuoka Airport) in Fukuoka city on 15 June. Reassembled, the aircraft was inspected on 19 June, but bombing raids caused some delays. Ground tests were soon conducted and indicated a tendency for the engine to overheat due to a lack of cooling airflow. Tsuruno attempted the first flight in July, but as the J7W1 began to take flight, the engine’s torque induced a roll to the right. The aircraft’s nose went high and caused the propeller tips to strike the ground, bending the tips back.

Kyushu-J7W1-Shinden-repair-right-side

Following World War II, the J7W1 was repaired and then painted before the aircraft was shipped to the United States. The new panels are easily seen in this image prior to the aircraft being repainted. Note that there is no cockpit glass.

The J7W1 was repaired, and the second prototype’s propeller was installed. A tailwheel from a Kyushu K11W Shiragiku (White Chrysanthemum) trainer was added under each vertical stabilizer so that during an over-rotation, a propeller strike would not occur again. Yoshitaka Miyaishi took over the flight tests and started over with ground runs to assess the aircraft’s handling. The J7W1 made its first flight on 3 August 1945. Liftoff occurred at 126 mph (204 km/h), and the aircraft was not flown above 1,312 ft (400 m). The speed did not exceed 161 mph (259 km/h), and the flight lasted under 15 minutes, with the aircraft landing at 115 mph (185 km/h). The J7W1’s tendency to roll to the right persisted and needed much left aileron input to correct, but the aircraft behaved reasonably well otherwise. Two further flights were made on 6 and 8 August, each about 15 minutes in length. The aircraft’s basic handling was evaluated, and the landing gear was never retracted during the tests. The roll to the right was made worse with the flaps deployed and the engine producing more torque to maintain airspeed. The J7W1 exhibited a tendency for its nose to pitch down, which was countered by a steady pull on the control stick. The engine, extension shaft, and remote gear reduction caused some vibration issues.

Modifications were contemplated to neutralize the engine’s torque reaction and correct the aircraft’s handling. A proposition was made to increase the foreplane’s angle of incidence to three degrees and change the main wing’s flap deployment to 30 degrees. In addition, the oil cooler needed to be improved. It was decided that speed tests would be initiated on the aircraft’s next flight, scheduled for 17 August. However, all work was stopped with the Japanese surrender on 15 August, and much of the aircraft’s documentation was burned on 16 August.

Kyushu-J7W1-Shinden-display

The J7W1 on display in Japan after it was repaired and painted. The inlet for the right oil cooler can be seen just behind the induction scoop, and the oil cooler’s exit can be seen right before the propeller. Note that the flaps are partially deployed.

At the end of the war, the second J7W1 was nearly complete and waiting on its [Ha-43] 42 engine, and the third aircraft was under construction. No other examples were completed to any meaningful level. The third J7W1 was planned to have the three-degree foreplane angle of incidence and a [Ha-43] 43 engine that produced an additional 130 hp (97 kW) for takeoff. This engine would have a single impeller for its first-stage, continuously-variable supercharger. The intake for the engine was moved to the inside of the J7W1’s cooling air inlets. The fourth and later aircraft would incorporate the changes from the third and also have a four-blade propeller 11 ft 6 in or 11 ft 10 in (3.5 m or 3.6 m) in diameter. The four-blade propeller had wider blades, was easier to manufacture, and was intended to cure some of the J7W1’s tendency to roll to the right. Beginning with the eighth aircraft, a 2,250 hp (1678 kW) [Ha-43] 51 engine would be installed. The [Ha-43] 51 had a single-stage, three-speed, mechanical supercharger instead of two-stage supercharging with a continuously-variable first stage.

The second and third J7W1 were both destroyed following the Japanese surrender. The first prototype, with around 45 minutes of flight time, was captured by US Marines and found to have all of the cockpit glass removed and some body panels damaged, possibly from a typhoon. For many years, it was thought that the first prototype was destroyed and that the second aircraft was captured by US forces, but this was later found to be incorrect. Under US orders, the aircraft was repaired and repainted while still in Japan. Most pictures of the J7W1 are immediately after the repairs have been made or shortly after it was painted. In almost all of the pictures, the cockpit glass is missing. In October 1945, the J7W1 was disassembled and shipped to the United States.

Kyushu-J7W1-Shinden-Tsuruno

Six US Servicemen and four Japanese dignitaries pose next to the J7W1. Masayoshi Tsuruno, the aircraft’s designer, is the fourth from the left. The men give a good indication of the aircraft’s tall stance and overall size.

The surviving J7W1 was assigned ‘Foreign Evaluation’ FE-326 (later T2-326), and attempts were made to bring the aircraft to a flightworthy status. It is believed that most of this work, including new cockpit glass and installing several American flight instruments, was conducted in mid-1946 at Middletown Air Depot (now Harrisburg International Airport) in Pennsylvania. In September 1946, the aircraft was moved to the Orchard Field Airport (now O’Hare Airport) Special Depot in Park Ridge, Illinois. Instructions indicated that the J7W1 could be made airworthy if an overhauled engine was found, but this never occurred and the aircraft was not flown in the United States. The J7W1 was transferred to the Smithsonian National Air and Space Museum in 1960. The aircraft is preserved in a disassembled and unrestored state, with the [Ha-43] 42 engine still installed in the fuselage. Amazingly, video of the aircraft’s aborted first flight attempt and eventual first flight can be found on YouTube.

Around 2016, a full-size model of the J7W1 was built by Hitoshi Sakamoto. The model was on special display at the Yoichi Space Museum in Hokkaido, but it is not known if it is still there.

A turbojet version of the aircraft had been considered from the start, but a suitable powerplant had not been built in Japan by the close of the war. Designated J7W2 Shinden-Kai, the jet aircraft most likely would have had shorter landing gear, with additional fuel tanks in the wings occupying the space formerly used by the longer gear. There is no indication that the J7W2 had progressed beyond the preliminary design phase before the war’s end.

Kyushu-J7W1-Shinden-NASM

Today, J7W1 is disassembled but fairly complete. However, the years of storage have led to many bent and dented parts. The aircraft was long stored in the Smithsonian National Air and Space Museum’s Paul E. Garber facility, but the cockpit and foreplanes are on display at the Steven F. Udvar-Hazy Center in Chantilly, Virginia. (NASM image)

Sources:
Zoukei-mura Concept Note SWS No. 1 J7W1 Imperial Japanese Navy Fighter Aircraft Shin Den by Hideyuki Shigete (2010)
Japanese Secret Projects by Edwin M. Dyer III (2009)
Japanese Aircraft of the Pacific War by René J. Francillon (1979/2000)
– “Kyushu Airplane Company” The United States Strategic Bombing Survey, Corporation Report No. XV (February 1947)
Encyclopedia of Japanese Aircraft 1900–1945 Vol. 4: Kawasaki by Tadashi Nozawa (1966)
The XPlanes of Imperial Japanese Army & Navy 1924–45 by Shigeru Nohara (1999)
War Prizes by Phil Butler (1994/1998)
https://www.secretprojects.co.uk/threads/kyushu-J7W1-shinden-J7W2-shinden-kai.16914/
https://airandspace.si.edu/collection-objects/kyushu-j7w1-shinden-magnificent-lightning

McDonnell-XP-67-top

McDonnell Aircraft Corporation XP-67 Fighter

By William Pearce

On 20 February 1940, the Army Air Corps (AAC) issued Request for Data R40-C that sought designs of new fighter aircraft capable of 450 mph (724 km/h), with 525 mph (845 km/h) listed as desirable. The AAC encouraged aircraft manufacturers to propose unconventional designs. The McDonnell Aircraft Corporation proposed four variants of its highly-streamlined Model 1 (often called Model I), the company’s first design. Each of the four Model 1 variants were powered by a different engine, and all the engines produced over 2,000 hp (1,491 kW). The Model 1’s engine was buried in the fuselage and drove wing-mounted pusher propellers via extensions shafts and right-angle gear boxes. Although not selected for R40-C, the AAC did purchase engineering data and a wind tunnel model of the design powered by an Allison V-4320 engine.

McDonnell-Model-2-original

The McDonnell Model 2 as originally proposed was similar to the Model 1 but with Continental XI-1430 engines mounted under the wings. This configuration was found to create excessive drag.

McDonnell worked with the AAC to refine the Model 1 design and submitted the Model 2 (often called Model II) on 30 June 1940. The Model 2 had a crew of two, and two wing-mounted Continental XI-1430 engines replaced the single engine in the fuselage. The aircraft retained the basic shape of the Model 1’s fuselage and wings, but the engines were initially mounted directly under the wings in a tractor configuration. The engine mounting was changed as a result of wind tunnel tests. The new configuration was to mount the engine forward of the wing with a nacelle that housed a turbosupercharger extending back past the wing’s trailing edge. The nacelle was mounted mid-wing, and this design minimized drag. To further reduce drag, the Model 2 design was modified to incorporate fairings that blended the fuselage and engine nacelles to the wings. In addition, the design had the pilot as the sole occupant. The single-seat, blended design was called the Model 2A (often called Model IIA), and it was submitted to the AAC on 24 April 1941.

On 5 May 1941, McDonnell submitted preliminary specifications of the Model 2A to the AAC. Under these specifications, the aircraft had a wingspan of 55 ft (16.8 m), a length of 42 ft 3 in (12.9 m), and a height of 14 ft 9 in (4.5 m). The Model 2A had a calculated speed of 500 mph (805 km/h) at 35,000 ft (10,668 km), 472 mph (760 km/h) at 25,000 ft (7,620 m), and 384 mph (618 km) at 5,000 ft (1,524 m). The aircraft would climb to 25,000 ft (7,620 m) in 9 minutes and have a service ceiling of 41,500 ft (12,649 m). At a cruising speed of 316 mph (509 km/h), maximum range was 2,400 miles (3,862 km) with 760 gallons (2,877 L) of internal fuel. The Model 2A had an empty weight of 13,953 lb (6,329 kg), a gross weight of 18,600 lb (8,437 kg), and a maximum weight of 21,480 lb (9,743 kg).

McDonnell-Model-2-revised

The Model 2 was revised with the engines mounted forward of the wings with streamlined nacelles mounted mid-wing. This produced a more attractive aircraft, very similar to the Model 1. However, the relation to the XP-67 is clear.

McDonnell continued to work with the AAC to refine the design of the Model 2A. On 30 September 1941, the Army Air Force (AAF—the AAC was renamed in June 1941) issued a contract to McDonnell to build two prototypes of the Model 2A interceptor pursuit fighter as the XP-67. The aircraft was assigned Materiel Experimental code MX-127. The first aircraft was scheduled to be delivered on 29 April 1943, with the second example delivered six months later on 29 October 1943. The XP-67 had a fairly conventional layout for a single-seat, twin-engine aircraft with tricycle undercarriage. What was not conventional was the extensive blending of the fuselage and engines nacelles to the aircraft’s wings to maintain true airfoil sections throughout the entire aircraft. The end result was a streamlined appearance.

The XP-67 was constructed of an aluminum frame with aluminum skin that formed a monocoque structure. All control surfaces consisted of a fabric covered aluminum frame, although aluminum skinning was later proposed for production aircraft. Effort was expended to keep the XP-67’s surface smooth and make everything flush. Initially, a door on the left side of the pressurized cockpit was to allow access. However, pressurization was dropped on the prototype, and a glazed, rearward-sliding canopy was used.

The wings had two spars, a dihedral of five degrees, and consisted of inner and outer wing sections. The outer wing section extended from the engine nacelle and was removable. Split flaps were located between the nacelle and fuselage. A small split flap existed on the outer side of the engine nacelle. The outer wing section’s trailing edge was occupied by an aileron. The ailerons drooped 15 degrees with deployment of the flaps, which had a maximum deployment of 45 degrees. However, it does not appear that the drooping ailerons were ever installed on the prototype. No hardpoints existed under the wings for bombs or drop tanks.

McDonnell-Model-2A-drawing

The Model 2A as originally proposed in May 1941 was essentially the latest Model 2 design but with large fairings that blended the fuselage and engine nacelles to the wing. This design was contracted as the XP-67.

Mounted to each wing was a liquid-cooled, Continental XI-1430 inverted V-12 engine. Initially, clockwise-rotating (right-handed) XI-1430-1 engines were to be used. In June 1942, the engines were switched to an XI-1430-17 installed on the right wing (clockwise, right-handed rotation) and an XI-1430-19 installed on the left wing (counterclockwise, left-handed rotation). Each engine of the first prototype turned a cuffed, four-blade Curtiss Electric constant-speed propeller that was 10 ft 6 in (3.2 m) in diameter. However, the cuffs were installed after the first aircraft was completed. In April 1943, McDonnell proposed installing Curtiss Electric contra-rotating propellers on the second XP-67 prototype, noting that such a change would increase the aircraft’s speed by 7–10 mph (11–16 km/h) and climb rate by 400 fpm (2.0 m/s).

The engine nacelle extended back from each engine and housed a General Electric D-23 turbosupercharger. Engine exhaust was directed straight back from the nacelle to gain some thrust. Initially, it was proposed that each engine would have a coolant radiator located in the fuselage. This was changed to each engine having two coolant radiators housed in the engine nacelle and located directly under the rear of the engine. The engine nacelles were blended into the wing, and several intakes were incorporated into the wing’s leading edge. For both engine nacelles, the intakes closest to the nacelle passed air to a cooling jacket around the exhaust manifold. The center intake directed air through the two coolant radiators per engine and to the turbosupercharger. The intakes farthest from the engine each led to an oil cooler.

An oil tank in each wing held 26 gallons (98 L) for each engine. The aircraft’s normal fuel load was 282 gallons (1,067 L), but 478 gallons (1,809 L) of additional fuel could be housed in the aircraft’s four fuel tanks located in the fuselage and wing. This brought the XP-67’s total fuel capacity to 760 gallons (2,877 L). The aircraft’s tricycle landing gear was hydraulically-powered and fully retractable. The nose wheel was swiveled, but was not steerable, and folded back into the fuselage. The main gear was mounted just inboard of the engine nacelles and folded inward. In early 1942, the AAF requested that the main gear fold into the engine nacelle, necessitating a complete redesign of the nacelles to accommodate the rearward retracting main wheels. The horizontal stabilizer had 9.55 degrees of dihedral and was mid-mounted to the aircraft’s vertical stabilizer. Like the outer wing panels, the tail was detachable for transporting the aircraft by ground. The XP-67 airframe was stressed for +8 and -4 Gs and had a diving limit of 604 mph (972 km/h) indicated.

McDonnell-XP-67-nacelle-LMAL

An XI-1430-17 with a GE D-23 turbosupercharger installed in the McDonnell XP-67 wing section for tests at the Langley Memorial Aeronautical Laboratory in September 1943. The tests were conducted to evaluate the cooling ducts of the XP-67’s radical blended design. The top image illustrates the unusual ducting of the XP-67’s nacelles, which were duplicated on the opposite side. Closest to the spinner is the exhaust manifold cooling air duct. The large middle duct was for the coolant radiator and engine intake. The outer duct was for the oil cooler. The bottom image shows the turbosupercharger, which was installed so that the exhaust provided additional thrust. Note the radiator cooling air exit duct on the landing gear door and the cuffed propellers. (LMAL images)

The XP-67’s armament changed as the aircraft was developed. Initially, the aircraft would have four 20 mm cannons with 166 rounds per gun and six .50-cal machine guns with 500 rounds per gun. The cannons would be installed on the sides of the cockpit, just behind the pilot. The machine guns were to be installed just behind the cannons. On 5 August 1941, the AAF requested that two 37 mm cannons be installed in place of two 20 mm cannons. By 16 August, the armament was revised again to six 37 mm cannons with 45 rounds per gun and no other guns. The 37 mm cannons were installed in the blended-wing’s leading edge between the cockpit and engine nacelle. The three cannons on each side of the fuselage were outside of the propeller arc. On 20 October, it was suggested that the aircraft’s design should incorporate provisions to replace four of the 37 mm cannons with four 20 mm cannons. On 8 November, it was decided that the first aircraft would have six 37 mm cannons, and the second aircraft would have two 37 mm and four 20 mm cannons.

Extensive wind tunnel tests were conducted on various XP-67 models throughout 1942 and 1943. These tests led to many minor changes in the aircraft. Much of this testing was focused on the extensive fairing used to blend the wing and fuselage. The cooling system was also carefully scrutinized with many minor changes taking place to the cooling ducts. A full-size mockup of the XP-67 was inspected in mid-April 1942, which led to more changes. The most significant changes were lengthening the aircraft’s nose by 15 in (381 mm) and changing the flight control actuation system from push-pull rods to cables. In May, a fuselage section was built to test fire the 37 mm cannons. The tests proved satisfactory, but McDonnell redesigned the 37 mm cannon installation in October, necessitating another mockup and more tests. The new 37mm cannon installation mockup successfully passed its tests in March 1944, but the armament was never installed in the prototype. On 17 June 1942, the decision was made to finish the prototype without a pressurized cockpit. In April 1943, there were discussions of cancelling the XP-67, but the aircraft was seen as a good way to test the experimental wing blending, cannon armament, and XI-1430 engines.

McDonnell-XP-67-construction

The McDonnell XP-67 nearly complete in mid-November 1943. Even though the nacelle’s duct design was found to be insufficient in the wind tunnel tests, the aircraft was not modified with a new design until later. Note the covered ports for 37 mm cannons on each side of the cockpit and that the propellers do not have their cuffs installed.

McDonnell had built a full-scale XP-67 engine nacelle for testing the XI-1430 engine installation. Tests were conducted by McDonnell starting in May 1943. After accumulating almost 27 hours of operation, the rig was sent to the National Advisory Committee for Aeronautics (NACA) at the Langley Memorial Aeronautical Laboratory (LMAL, now Langley Research Center) in Virginia. The NACA added about 17.5 hours to the engine conducting tests in August and September to analyze the installation’s effectiveness for cooling the coolant, oil, and intercooler. The tests indicated that the cooling system was insufficient. The nacelle with revised ducts was then shipped to Wright Field in Dayton, Ohio in October 1943. Wright field added another 6.5 hours to the engine, bringing the total to 51 hours. The new ducts proved satisfactory, reducing the drag of the ducts by 25 percent and improving cooling by 200 percent. However, excessive vibrations occurred between the engine and its mounting structure, necessitating a more rigid mount. McDonnell was allowed to proceeded with testing the first XP-67, although the prototype would not be changed until after its first flight when additional changes beyond the cooling system would most likely need to take place. Wind tunnel tests had indicated that the horizontal stabilizer would need to be raised by 12 in (305 mm) to improve stability. McDonnell was instructed to stop work on the second prototype until successful flight tests of the first aircraft had been conducted.

Serial number 42-11677 was given to the first XP-67, and serial number 42-11678 was given to the second prototype. Unofficially, the XP-67 was given the name ‘Moonbat’ or just ‘Bat,’ but it does not appear that an official name was ever bestowed upon the aircraft. With all the design changes since the XP-67 was initially contracted, the aircraft’s specifications had changed. The wingspan remained at 55 ft (16.8 m), but the length increased 2 ft 6 in (.8 m) to 44 ft 9 in (13.6 m), and the height increased 1 ft (.3 m) to 15 ft 9 in (4.8 m). The standard fuel load remained at 280 gallons (1,060 L), but the additional fuel load decreased by 25 gallons (95 L) to 455 gallons (1,722 L), giving a total maximum internal fuel load of 735 gallons (2,782 L). The XP-67’s weight had increased by 3,792 lb (1,720 kg), resulting in an empty weight of 17,745 lb (8,049 kg), a gross weight of 22,114 lb (10,031 kg), and a maximum weight of 24,836 lb (11,265 kg). A reduction in performance accompanied the weight increase, resulting in an estimated speed of 448 mph (720 km/h) at 25,000 ft (7,620 m), which was a 24 mph (39 km/h) reduction, and 367 mph (591 km/h) at sea level. The time to climb to 25,000 ft (7,620 m) was increased by nearly five minutes to 14.8 minutes, and the service ceiling decreased 4,100 ft (1,250 m) to 37,400 ft (11,400 m). The XP-67’s cruising speed decreased 46 mph (74 km/h) to 270 mph (435 km/h), but maximum range was little changed at 2,385 miles (3,838 km) with 735 gallons (2,782 L) of fuel.

McDonnell-XP-67-right-front

The completed XP-67 with revised nacelle cooling ducts and after the horizontal stabilizer was raised 12 in (305 mm). The most noticeable duct modification was to the exhaust manifold cooling intake, which was changed to a scoop. Note that the propellers rotated in opposite directions.

On 1 December 1943, the XP-67 had its XI-1430 engines installed and was ready for ground tests. However, both engines caught fire and damaged the aircraft on 8 December. The fires were caused by issues with the exhaust manifolds. The XP-67 was repaired and made its first flight on 6 January 1944, taking off from Scott Field in Belleville, Illinois. The flight was nearly two years later than the anticipated first flight when the XP-67 contract was originally issued. Test pilot Ed E. Elliott had to cut the flight to just six minutes due to both turbosuperchargers overheating, which resulted in small fires. During the short flight, the XP-67 exhibited good handling characteristics.

The aircraft was again repaired, with the second and third flights occurring on 26 and 28 January 1944. On 1 February, the aircraft’s fourth flight was cut short due to a main bearing failure on the left engine caused by an unintentional overspeed of the engine. The cockpit canopy also detached during the flight. While the XP-67 was down for repairs and new XI-1430 engines, the horizontal stabilizer was raised 12 in (305 mm). The cooling ducts in the engine nacelles were also modified, with the most noticeable being the exhaust shroud inlet, which was changed to more of a scoop. The updated aircraft flew again on 23 March 1944 and demonstrated improved stability, but one turbosupercharger failed at 10,000 ft (3,048 m).

In April 1944, it was reported that the engines were running too cool. The closed main gear door formed part of the air duct aft of the radiator. However, the gear doors did not seal tightly and caused an excessive amount of air to exit the duct. This resulted in too much air passing through the radiator and reducing the engine temperature below ideal levels. McDonnell was allowed to install a thermostat on the prototype to help control coolant temperatures but was also told that such issues would not be acceptable on production aircraft. Around this same time, construction of the second prototype was allowed to proceed with the exception of parts that would be affected by an engine change.

McDonnell-XP-67-top

The unusual planform of the XP-67 is illustrated in this view. The two ports in the middle of each nacelle were the forward exit for the exhaust manifold cooling air. The rear exit is denoted by the white staining at the end of the nacelle. The outer wing section was detachable just outside of the nacelle.

In May 1944, three AAF pilots flew the XP-67 and reported that the XI-1430 engines ran rough and seemed underpowered. Tests indicated that at normal power, the engines were only delivering 1,060 hp (790 kW), well below the expected 1,350 hp (1,007 kW). The XP-67 was noted for having high control forces at high speeds, exhibiting a Dutch roll indicating some directional instability, and not making a good gun platform. The maximum speed with the engines delivering 1,600 hp (1,193 kW) at 3,200 rpm was 357 mph (574 km/h) at 10,000 ft (3,048 m) and 393 mph (632 km/h) at 20,000 ft (6,096 m). From these values and other tests, McDonnell calculated that the XP-67 could attain 405 mph (652 km/h) at 25,000 ft (7,620 m) at the same power setting. Takeoff speed was 130 mph (209 km/h); the clean stall speed was 118 mph (190 km/h) with buffeting starting at 140 mph (225 km/h); and the aircraft had a high landing speed of 120 mph (193 km/h). In general, the XP-67 was found to be inferior to other fighters currently in production.

McDonnell got permission to install contra-rotating propellers on the first prototype when the engines were ready, and they were expected in June 1944. No information has been found indicating that the contra-rotating versions of the XI-1430 were delivered. In June, it was decided to install 11 ft (3.4 m) diameter four-blade Aeroproducts propellers rather than contra-rotating propellers. However, tests would continue with the Curtiss propellers until the Aeroproducts were ready. It was also noted that the XP-67 had experienced no engine fires since its fourth flight, and the aircraft had completed about 50 flights without any serious issues.

McDonnell-XP-67-in-flight

The limited flight trials of the XP-67 indicated the aircraft handled fairly well. It was noted as underpowered and slightly unstable. Overall, visibility was said to be poor, with the engine and fairing blocking most of the view to the side and rear. Formation flying would have been difficult, as the pilot was unable to see their wingtips.

In July 1944, some in the AAF felt that the XP-67 program was expensive and served no purpose. However, others felt that the aircraft was a unique platform that would allow the testing of the six 37 mm cannons. In addition, the possibility existed to install 12 .50-cal machine guns or eight 20 mm cannons. The aircraft was seen as a good test machine, even if its performance fell below what was originally specified. It was decided to complete tests on the current aircraft to assess the blended design and then consider the possibility of armament trials.

McDonnell had long sought to change the aircraft’s engines. On 19 January 1944, McDonnell proposed discarding the XI-1430s for the second prototype and using either two-stage Allison V-1710 or Rolls-Royce Merlin RM 14SM (100-series prototype) piston engines. In addition, each engine nacelle would house a Westinghouse 9.5 (J32) turbojet behind the piston engine. The mixed-power proposal was brought up again on 16 March 1944, now using an Allison V-1710-199 (F32R) piston engine and either a Rolls-Royce W2B/37 turbojet or a GE I-20 (J39) turbojet in the nacelle. With mixed power plants, the aircraft had an estimated top speed at sea level of 500 mph (805 km/h). The engine issue was discussed again in July 1944, with McDonnell now suggesting a Rolls-Royce Merlin RM 14SM piston engine paired with a GE I-20 (J39) turbojet in each nacelle. However, AAF felt that the aircraft would need a complete redesign to incorporate different piston engines with turbojets.

Since its initial design in May 1941, there were suggestions of using a modified version of the XP-67 for photo reconnaissance. In April 1942, McDonnell suggested that the aircraft’s range could be extended to 4,000 miles (6,437 km) at a cruise speed of 200 mph (322 km/h), which would be a 20-hour flight. For this, two of the 37 mm cannons would need to be omitted and six additional fuel tanks installed along with 280 lb (127 kg) of ballast in the nose. With the extra tanks, the aircraft’s internal fuel capacity was 1,290 gallons (4,883 L). This concept was not pursued at the time, but the range extension was considered later for a photo-recon role.

McDonnell-XP-67E-model

A model of the XP-67E with its bubble canopy and mixed piston / turbojet power plants. It is not clear what engines (if any) are intended to be depicted by the model, but the nacelles were extended back to house the jet engine (LMAL image).

By July 1944, it was believed that a photo-recon version of the XP-67 would have inferior performance compared to the Lockheed F-5 (P-38). However, a mixed-power version of the aircraft was seen as a possible candidate as a photo-recon aircraft. The XP-67E was designed for the photo-recon role, and it incorporated mixed power, additional internal fuel tanks, and provisions for two 150-gallon (568-L) drop tanks mounted under the aircraft’s center section. In the XP-67E design, the engine nacelles were extended back to house the GE I-20 (J39) turbojet engine. Cameras were installed in the aft fuselage, and the XP-67E was unarmed. The fuselage was mostly unchanged, but the cockpit was enclosed in a rearward-sliding bubble canopy.

The XP-67 prototype had been undergoing modifications and repairs through August 1944. Perhaps the most major change was alerting the wing dihedral from 5 degrees to 7 degrees in an attempt to increase stability. The aircraft was ready to resume flight tests in early September. On 6 September 1944, the exhaust valve rocker of the No. 1 cylinder in the XP-67’s right engine broke while the aircraft was in flight at 10,000 ft (3,048 m). Exhaust gases unable to escape the cylinder backed up into the intake manifold and caused it to fail, resulting in a fire. The fire was first noticed at 3,000 ft (914 m) as the aircraft was preparing to land. Test pilot Elliott was able to land the XP-67 and stopped it to limit the flames from spreading. However, the brake failed after Elliott exited the aircraft, and wind turned the XP-67 so that the flames blew toward the fuselage. The XP-67 was nearly burned in half and damaged beyond repair. The aircraft had a total flight time of 43 hours. This event effectively killed the XP-67 project and the XP-67E photo-recon proposal. The entire program was suspended seven days later on 13 September, and on 24 October, McDonnell was notified that the XP-67 contract was cancelled. A formal Notice of Cancellation followed on 27 October 1944. The second prototype was about 15 percent complete and was subsequently scrapped. The total cost of the XP-67 program was approximately $4,733,476.92.

McDonnell-XP-67-fire-front

The XP-67 after the fire on 6 September 1944. Once on the ground, the fire from the right engine spread to the rear fuselage and left nacelle. The rear fuselage was nearly burned through and collapsed to the ground. An inglorious end to both the XP-67 and XI-1430 programs.

Sources:
Interceptor Pursuit Airplane Twin Engine Type XP Preliminary Specifications by McDonnell Aircraft Corporation (5 May 1941)
Memorandum Report on XP-67 Airplane, AAF No, 42-11677 by Osmond J. Ritland (19 May 1944)
Final Report on the XP-67 Airplane by John F Aldridge Jr. (31 January 1946)
Case History of XP-67 Airplane by Historical Division, Air Materiel Command (23 July 1946)
USAF Fighters of World War Two Volume Three by Michael O’Leary (1986)
U.S. Experimental & Prototype Aircraft Projects: Fighters 1939-1945 by Bill Norton (2008)

Curtiss-XF14C-2-front-left

Curtiss XF14C Carrier-Based Fighter

By William Pearce

On 30 June 1941, the United States Navy, in preparation for the future of aerial combat, ordered prototypes of the Grumman F6F Hellcat carrier fighter and the F7F Tigercat heavy fighter. The Hellcat was intended to replace the F4F Wildcat and counter the Japanese Mitsubishi A6M Zero. The Tigercat was intended to out-perform and out-gun all other fighters. The Hellcat and Tigercat went on to serve with distinction for many years. Also on 30 June 1941, the Navy ordered two prototypes of the Curtiss XF14C.

Curtiss-XF14C-2-front-left

The Curtiss XF14C-2 with its contra-rotating propellers and four 20 mm cannons appears as an imposing aircraft. However, its performance did not meet expectations. Note the stagger of the cannons and the glazed, rearward-sliding canopy.

Since 1939, the Navy had been supporting the development of the 2,300 hp (1,715 kW) Lycoming XH-2470 engine. The XH-2470 was a liquid-cooled, 24-cylinder engine in a vertical H configuration. The Navy’s support for the XH-2470 was unusual, as it had a long history of exclusively using air-cooled radial engines. In addition, the Navy had no applications for the engine until the XF14C was proposed as a high-performance fighter.

The Curtiss-Wright XF14C was designed at the company’s main facility in Buffalo, New York. The two XF14C-1 prototypes ordered were assigned Navy Bureau of Aeronautics numbers (BuNo) 03183 and 03184. Most sources state that the XF14C-1 was to be powered by the XH-2470-4 engine. Lycoming documents indicate that the -4 featured contra-rotating propellers. However, some sources state the XF14C-1 had a single rotation propeller that was 14 ft 2 in (4.32 m) in diameter. The XH-2470-2 used a single rotation propeller, but no sources have been found specifically stating that this was the engine for XF14C-1.

Regardless of the exact engine model and propellers, the XF14C-1 was an all-metal, low-wing aircraft with standard landing gear and a conventional layout. The gear was fully retractable, including the tail-wheel, and the main legs had a wide track. The arrestor tail hook extended from the extreme rear of the fuselage. The outer panels of the wings had around 7.5 degrees of dihedral and folded up for aircraft storage on an aircraft carrier. The fixed wing section had a flap along its trailing edge, and the folding section had a small flap on its inner trailing edge. The rest of the folding section had an aileron along its trailing edge. Just inboard of the wing-fold was the aircraft’s armament. Initially, each wing would house three .50-cal machine guns, but this was revised to two 20 mm cannons with 166 rounds per gun.

Curtiss-XF14C-2-right-side

Side profile of the XF14C-2 illustrates the large exhaust pipe from the turbosupercharger under the aircraft. The inscription under the diving figure on the cowling reads “Coral Princess.” Note the large wheel covers and the retracted tail hook.

The XF14C-1 had a 46 ft (14.02 m) wingspan, was 38 ft 4 in (11.68 m) long, and was 14 ft 6 in (4.42 m) tall. With the wings folded, the aircraft’s span was 22 ft 6 in (6.89 m). The XF14C-1 had an estimated speed of 344 mph (554 km/h) at 3,500 ft (1,067 m) and 374 mph (602 km/h) at 17,000 ft (5,182 m). Its initial rate of climb was 2,810 fpm (14.3 m/s), and it had a service ceiling of 30,500 ft (9,296 m). The aircraft had an empty weight of 9,868 lb (4,476 kg), a gross weight of 12,691 lb (5,757 kg), and a maximum weight of 13,868 lb (6,290 kg). The XF14C-1 had a range of 1,080 miles (1,738 km) at 176 mph (283 km/h) on 230 US gallons (192 Imp gal / 871 L) of internal fuel. With two 75-US gallon (62 Imp gal / 284 L) drop tanks, range increased to 1,520 miles (2,446 km) at 164 mph (264 km).

Wind tunnel tests conducted by the Navy in October 1942 indicated that the Curtiss-provided performance specifications for the XF14C-1 were optimistic, but the program moved forward. The first airframe (BuNo 03183) was mostly complete by September 1943. However, delays with the XH-2470 left the XF14C-1 without an engine. The engine delay gives some credence to a contra-rotating version of the XH-2470 being used in the XF14C-1. A single rotation XH-2470 had passed a Navy acceptance test in April 1941, and a single rotation XH-2470 that was delivered to the Army Air Force had made its first flight in the Vultee XP-54 on 15 January 1943. With the availability of the single-rotation XH-2470 for the Army Air Force, it seems that such an engine could have been supplied to Curtiss for the XF14C-1 if that is what the aircraft needed. The Navy subsequently dropped its participation in the XH-2470 engine program, and the XF14C-1 was cancelled in December 1943.

Curtiss and the Navy negotiated to proceed with the XF14C program by changing the engine to the experimental Wright XR-3350-16. The -16 was turbosupercharged and used contra-rotating propellers. Rated at 2,250 hp (1,678 kW) at 32,000 ft (9,754 m), the 18-cylinder, air-cooled, radial engine offered a higher service ceiling than the XH-2470. This interested the Navy, as they were looking toward developing a high-altitude interceptor. With the new engine, the Curtiss aircraft became the XF14C-2 and was pushed into a high-altitude fighter role. The cancellation of the XF14C-1 terminated all work on the second prototype, BuNo 03184, which was never built.

Curtiss-XF14C-2-wings-folded

The XF14C-2’s outer wing section folded up just outside of the cannons. Note the gap around the spinner for cooling the two-row, 18-cylinder R-3350 engine and that the second set of propeller blades have cuffs to aid cooling.

BuNo 03183 became the XF14C-2 and was modified to accept the new engine. A six-blade, contra-rotating Curtiss Electric propeller with a diameter of approximately 12 ft 10 in (3.91 m) was installed on the XR-3350-16 engine. The cowling incorporated an intake scoop under the engine. Oil coolers were placed in extensions of the XF14C-2 wing roots. The turbosupercharger was installed directly behind the engine in a housing that extended back from the lower cowling. A large exhaust pipe from the turbosupercharger extended below the aircraft behind the main wheels.

The Curtiss XF14C-2 had the same 46 ft (14.02 m) wingspan as the XF14C-1 but was shorter at 37 ft 9 in (37.75 m) long and 12 ft 4 in (3.76 m) tall. The aircraft had an estimated speed of 317 mph (510 km/h) at sea level and 424 mph (682 km/h) at 32,000 ft (9,754 m). The XF14C-2’s initial rate of climb was 2,700 fpm (13.7 m/s), and it had a service ceiling of 39,500 ft (12,040 m). The aircraft had an empty weight of 10,582 lb (4,800 kg), a gross weight of 13,405 lb (6,080 kg), and a maximum weight of 14,950 lb (6,781 kg). At a cruising speed of 172 mph (277 km/h), the XF14C-2 had a range of 950 miles (1,529 km) on 230 US gallons (192 Imp gal / 871 L) of internal fuel and 1,355 miles (2,181 km) with two 75-US gallon (62 Imp gal / 284 L) drop tanks.

The XF14C-2 was first flown in July 1944 and delivered to the Navy on 2 September 1944. Testing quickly revealed that the aircraft did not meet the expected performance and offered no advantage over fighters already in service. Top speeds of only 300 mph (483 km/h) at sea level and 398 mph (641 km/h) at 32,000 ft (9,754 m) were achieved. The aircraft’s engine and propeller combination also caused a bad vibration throughout the airframe. With the XF14C-2 underperforming, no urgent need for a high-altitude fighter, and all the R-3350 production dedicated for the Boeing B-29 Superfortress and Convair B-32 Dominator bombers, the Navy cancelled the XF14C-2. The airframe was eventually scrapped. The XF14C-2 was the last piston-engine fighter built by Curtiss.

Curtiss proposed the XF14C-3 to truly fulfill the role of a high-altitude fighter. It had a pressurized cockpit and could operate at 40,000 ft. Studies of the XF14C-3 were conducted at Navy expense until early 1945, but no aircraft was built.

Curtiss-XF14C-2-front-right

The XF14C-2 had oil-coolers in the wing roots. Note the dihedral angle of the outer wing sections. The engine and propeller combination caused an unacceptable level of vibration.

Sources:
Curtiss Fighter Aircraft by Francis H. Dean and Dan Hegedorn (2007)
US Experimental & Prototype Aircraft Projects: Fighters 1939-1945 by Bill Norton (2008)
American Secret Projects 1 by Tony Buttler and Alan Griffith (2015)
To Join with the Eagles by Murry Rubenstein and Richard M. Goldman (1974)
The American Fighter by Enzo Angelucci and Peter Bowers (1987)

Latecoere 631-03

Latécoère 631 Flying Boat Airliner

By William Pearce

On 12 March 1936, the civil aeronautics department of the French Air Ministry requested proposals for a commercial seaplane with a maximum weight of 88,185 lb (40,000 kg) and capable of carrying at least 20 passengers (with sleeping berths) and 1,100 lb (500 kg) of cargo 3,730 miles (6,000 km) against a 37 mph (60 km/h) headwind. In addition, the aircraft needed a normal cruising speed of 155 mph (250 km/h). This large passenger aircraft was to be used on transatlantic service to both North and South America. Marcel Moine, head engineer at Latécoère (Société Industrielle Latécoère, SILAT) had already been working on an aircraft to meet similar goals. In late 1935, Moine had designed an aircraft for service across the North Atlantic with a maximum weight of 142,200 lb (64,500 kg). However, the design was seen as too ambitious. Moine modified the design to meet the request issued in 1936, and the aircraft was proposed to the Air Ministry as the Latécoère 630.

Latecoere 631-04

The Latécoère 631 was one of the most impressive flying boats ever built. Unfortunately, its time had already passed before the aircraft could enter service. Laté 631-04 (fourth aircraft) F-BDRA is seen here, and it was the second of the type in service for Air France. Note the configuration of the flaps and ailerons.

The Laté 630 was an all-metal, six-engine flying boat with retractable floats. The 930 hp (694 kW), liquid-cooled Hispano Suiza 12 Ydrs was selected to power the 98,860 lb (44,842 kg) aircraft, which had a 187 ft (57.0 m) wingspan, was 117 ft 9 in (35.9 m) long, and had a range of 4,909 miles (7,900 km). On 15 November 1936, order 575/6 was issued for detailed design work of the Laté 630 and a model for wind tunnel tests. This was followed by order number 637/7 for a single Laté 630 prototype on 15 April 1937. However, the Air Ministry cancelled the Laté 630 on 22 July 1937, stating that advancements in aeronautics enabled the design and construction of a larger and more capable aircraft. Construction of the Potez-CAMS 161, which was designed under the same specifications as the Laté 630, was allowed to continue.

Taking aeronautical advancements into consideration, the Air Ministry issued an updated request for an aircraft with a maximum weight of 154,323 lb (70,000 kg) and capable of transporting 40 passengers and 11,000 lb (5,000 kg) of cargo with a normal cruising speed of over 186 mph (300 km/h). To meet the new requirements, Moine and Latécoère enlarged and repowered the Laté 630 design, creating the Laté 631. In October 1937, detailed design work and a wind tunnel model of the Laté 631 were ordered. Order number 597/8 for a single prototype was issued on 1 July 1938. A Lioré et Olivier H-49 (which became the SNCASE SE.200) prototype was also ordered under the same specification as the Laté 631.

The Latécoère 631 was an all-metal flying boat with a two-step hull. The monocoque fuselage consisted of an aluminum frame covered with aluminum sheeting. The interior of the hull was divided into numerous passenger compartments and included a lounge/bar under the radio/navigation room (may have been in the nose in some configurations) and a kitchen at the rear. The cockpit and radio/navigation room were located above the main passenger compartment and just ahead of the wings. The cockpit was positioned rather far back from the nose of the aircraft. Numerous access doors were provided, including in the nose, side of the cockpit, and in the sides of the fuselage.

Latecoere 631 cockpit

The cockpit of the Laté 631 was rather spacious. Note the six throttle levers suspended above the pilot’s seat. The copilot could not reach the levers, but the flight engineer had another set of throttles. The central pylon contained the trim wheels and controls for the floats and flaps. At left in the foreground is the navigation station, and the radio station is at right.

The high-mounted wing was blended to the top of the fuselage and carried the aircraft’s six engines in separate nacelles. The wing had two main spars and a false spar. Each wing consisted of an inner section with the engine nacelles and an outer section beyond the nacelles. The outer engine nacelle on each wing incorporated a retractable float that extended behind the wing’s trailing edge. Due to interference, the float needed to be at least partially deployed before the flaps could be lowered. A passageway in the wing’s leading edge was accessible from the radio/navigation room and allowed access to the engine nacelles. Each nacelle had two downward-opening doors just behind the engine that served as maintenance platforms. A section of the firewall was removable, allowing access to the back of the engine from within the nacelle. Between the inboard engine and the fuselage was a compartment in the wing’s leading edge designed to hold mail cargo.

Originally, 1,500 hp (1,119 kW) Gnôme Rhône 18P radial engines were selected to power the Laté 631. However, the availability of these engines was in question, and a switch to 1,600 hp (1,193 kW) Wright R-2600 radial engines was made. The Gnôme Rhône 14R and the Pratt & Whitney R-2800 were also considered, but the 14R was also unavailable, and the export of R-2800 engines was restricted. Each engine turned a three-blade, variable-pitch propeller that was 14 ft 1 in (4.3 m) in diameter and built by Ratier. Later, larger propellers were used, but sources disagree on their diameter—either 14 ft 5 in or 15 ft 1 in (4.4 m or 4.6 m). It is possible that both larger diameters were tried at various times.

At the rear of the aircraft were twin tails mounted to a horizontal stabilizer that had 16.7 degrees of dihedral. All control surfaces had an aluminum frame with a leading edge covered by aluminum. The rest of the control surface was fabric covered. Movement of the control surfaces was boosted by a servo-controlled electrohydraulic system, which could be disengaged by the pilot. The slotted aileron on each wing was split in the middle and consisted of an outer and an inner section. The ailerons also had Flettner servo tabs that were used to trim the aircraft and could be engaged to boost roll control.

Latecoere 631-01 German 63-11

Laté 631-01 (F-BAHG) in German markings as 63+11. The openings for the large passenger windows existed in the airframe but were covered on Laté 631-01. The prototype aircraft was destroyed during an allied attack while in German hands on Lake Constance in April 1944.

Six wing tanks carried 7,582 gallons (28,700 L) of fuel, and each tank fed one engine. During flight, these tanks were replenished by pumping fuel from six tanks in the hull that carried 5,785 gallons (21,900 L) of fuel. The Laté 631’s total fuel capacity was 13,367 gallons (50,600 L). Each engine had its own 111-gallon (422-L) oil tank.

The Latécoère 631 had a 188 ft 5 in (57.43 m) wingspan, was 142 ft 7 in (43.46 m) long, and was 33 ft 11 in (10.35 m) tall. The aircraft had a maximum speed of 245 mph (395 km/h) at 5,906 ft (1,800 m) and 224 mph (360 km/h) at sea level. Its cruising speed was 183 mph (295 km/h) at 1,640 ft (500 m). The Laté 631 had an empty weight of 89,265 lb (40,490 kg) and a maximum weight of 163,347 lb (75,000 kg). The aircraft had a 3,766-mile (6,060-km) range with an airspeed of 180 mph (290 km/h) against a 37 mph (60 km) headwind.

Construction of the Laté 631 was started soon after the contract was issued. However, work was halted on 12 September 1939 so that Latécoère could focus on production of desperately needed military aircraft after war was declared on Germany. After the French surrender, work on the Laté 631 resumed in July 1940 but was halted again on 10 November by German order. The French and Germans negotiated over continuing work on the aircraft, which was purely for civil transportation. The Germans allowed construction to continue, and a second prototype was ordered under the same contract as the first (597/8) on 19 March 1941. The 35 Wright R-2600 engines that had been ordered were stranded in Casablanca, Morocco by the outbreak of the war in 1939. Amazingly, the hold on these engines was released, and they were delivered at the end of 1941.

Latecoere 631-02 stripes

Laté 631-02 (F-BANT) was finished at the end of the war and painted with invasion stripes for (hopefully) easy identification. The aircraft is at Biscarrosse undergoing tests, probably around the time of its first flight on 6 March 1945. Like on the prototype, the passenger windows are covered, but the windows were later added. Note the retractable float and that engine No. 5 is running.

The Laté 631-01, the first prototype, was registered as F-BAHG and completed at Toulouse, France in the summer of 1942. The aircraft was then disassembled and transported, with some difficulty, 310 miles (500 km) to Marignane in southern France. The aircraft was then reassembled for subsequent tests on Étang de Berre. The SNCASE SE.200, the Laté 631’s competitor, was built at Marignane and was nearing completion at the same time. The reassembly of Laté 631-01 was completed in October 1942, and the aircraft made its first flight on 4 November with Pierre Crespy as the pilot. Seven others, including Moine, were onboard as crew and observers. A second flight was made on 5 November, and flutter of the aileron and wing was encountered at 143 mph (230 km/h). The issues were traced to an improperly made part in the aileron control circuit that had subsequently failed.

Laté 631-01 was repaired, but German occupation of the French free zone on November 1942 brought a halt to further flight tests. On 23 November, order 280/42 was issued for two additional Laté 631s, bringing the total to four aircraft. The Germans lifted flight restrictions, and Laté 631-01 was flown again in December 1942. Test flights continued but were halted on several occasions by German orders. In April 1943, the tests were allowed to continue provided the aircraft was painted in German colors with German markings and a Lufthansa pilot was on board during the flights. Germany had essentially seized Laté 631-01 (and the SE.200) at this point and believed the aircraft could be used as a commercial transport once the “quick” war was concluded. The Germans were also interested in ways to add armament to the flying boat and make it a maritime patrol aircraft. Laté 631-01 was repainted and carried the German code 63+11 (for 631-01).

Laté 631-01 flight testing resumed in June 1943. On 20 January 1944, the aircraft took off on its 46th flight, and it was the first flight in which its gross weight exceeded 154,323 lb (70,000 kg). A second flight was made at 157,630 lb (71,500 kg). The tests had demonstrated that at 88,185 lb (40,000 kg), the Laté 631 could hold its course with three engines on the same side shut down. At 154,323 lb (70,000 kg), the course could be held with the outer two engines shut down on the same side. Some additional indications of flutter had been encountered but not understood.

Latecoere 631-02 Brazil

Laté 631-02 at Rio de Janeiro, Brazil in late October 1945. Note the open nacelle platforms, which were accessible through a wing passageway. A Brazilian flag is attached to the forward antenna mast.

Around 22 January 1944, Laté 631-01 was taken over by German forces and flown to Lake Constance (Bodensee) and moored offshore from Friedrichshafen, Germany. The SE.200 had already suffered the same fate on 17 January. On the night of 6 April 1944, Laté 631-01 and the SE.200 were destroyed at their moorings on Lake Constance by an Allied de Haviland Mosquito. The Laté 631 prototype had accumulated approximately 48 hours of flight time.

Construction of other Laté 631 aircraft had continued until early 1944, when German forces wanted Latécoère to focus on building the Junkers 488 bomber (which was never completed and was destroyed by the French Resistance). The disassembled second Laté 631 (631-02) was hidden in the French countryside until the end of the war. On 11 September 1944, order 51/44 was issued for five additional Laté 631 aircraft, which brought the total to nine. In December 1944, the components of Laté 631-02 were transported to Biscarrosse, where the aircraft was completed and assembled for testing on Lac de Biscarrosse et de Parentis. On 6 March 1945, Crespy took Laté 631-02 aloft for its first flight. While testing continued, the aircraft was christened Lionel de Marmier and was registered as F-BANT in April 1945. On 31 July, Laté 631-02 started a round trip of over 3,730 miles (6,000 km) to Dakar, Senegal, returning to Biscarrosse on 4 August. On 24 August, material for two additional Laté 631s was added to order 51/44, enabling the production of up to 11 aircraft.

On 28 September 1945, an issue with the autopilot in Laté 631-02 caused a violent roll to the right that damaged the wing, requiring the replacement of over 8,000 rivets to affect repairs. The aircraft was quickly fixed so that a scheduled propaganda flight to Rio de Janeiro, Brazil could be made on 10 October 1945. On that day, Laté 631-02 collided with a submerged concreate mooring block while taxiing and tore a 6 ft 7 in (2 m) gash in the hull. Upset over this incident, French authorities took the opportunity to nationalize the Latécoère factories. Production of the last six Laté 631 aircraft was spread between AECAT (which was formed from Latécoère), Breguet, SNCASO, and SNCAN. SNCASO at Saint-Nazaire would be primarily responsible for the production of aircraft No. 6, 8, and 10, and SNCAN at Le Havre would be primarily responsible for aircraft No. 7, 9, and 11. Laté 631-02 eventually made the flight to Rio de Janeiro, with 45 people on board, arriving on 25 October 1945.

Latecoere 631-03

Laté 631-03 (F-BANU) was the third aircraft completed. Its first flight was on 15 June 1946, and it crashed during a test flight on 28 March 1950 while investigating the loss (in-flight break up) of Laté 631-06 on 1 August 1948. Investigation of Laté 631-03’s crash revealed vibration issues with the engines and wings, and led to a solution to prevent further accidents.

On 31 October 1945, the first tragedy struck the Laté 631 program. While on a flight between Rio de Janeiro and Montevideo, Uruguay with 64 people on board, Laté 631-02 suffered a propeller failure on the No. 3 (left inboard) engine. The imbalance caused the No. 3 engine to rip completely away from the aircraft. A separated blade damaged the propeller on the No. 2 engine (left middle), which resulted in that engine almost being ripped from its mounts. Another separated blade flew through the fuselage, killed one passenger, and mortally wounded another (who later died in a hospital). An emergency landing was performed on Laguna de Rocha in Uruguay. The failure of the Ratier propeller was traced to its aluminum hub, which was subsequently replaced with a steel unit. The recovery of the aircraft was performed by replacing the missing engine with one from the right wing. The four-engine aircraft, with a minimal crew, was flown to Montevideo on 13 November for complete repairs, which took three months.

In February 1946, three Laté 631 aircraft were purchased by Argentina, but this deal ultimately fell through, with Argentina never paying for the aircraft. In May 1946, an agreement was reached in which Air France would take possession of three Laté 631 aircraft. On 15 June 1946, Jean Prévost made the first flight of Laté 631-03 at Biscarrosse. The aircraft was registered as F-BANU, christened as Henri Guillaumet, and soon transferred to Air France.

Laté 631-04 was registered as F-BDRA, and its first flight occurred on 22 May 1947 at Biscarrosse. The aircraft was the second Laté 631 to go to Air France. Laté 631-05 was registered as F-BDRB, and its first flight occurred on 22 May 1947. Laté 631-06, registered as F-BDRC, made its first flight on 9 November 1947, taking off from the Loire estuary near Saint-Nazaire, France. Laté 631-06 F-BDRC was the third aircraft for Air France.

Latecoere 631-05

Laté 631-05 (F-BDRB) first flew on 22 May 1947. The aircraft was slated to be converted into a cargo transport, but that never occurred. The aircraft was damaged beyond economical repair during a hangar collapse in February 1956.

Laté 631-07, registered as F-BDRD, made its first flight on 27 January 1948. The aircraft was lost on 21 February during a test flight from Le Havre to Biscarrosse. Laté 631-07 had taken off in poor weather and was not equipped for flying on instruments alone. It crashed into the English Channel (Bay of Seine) off Les-Dunes-de-Varreville (Utah Beach). A definitive cause was never found, but it was speculated that either the pilot lost spatial orientation and crashed into the sea, or that the pilot was flying very low or trying to land after the weather closed in and struck wreckage left behind from the D-Day landings at Utah Beach. Regardless, all 19 on board, which were the crew and Latécoère engineers, were killed.

On 1 August 1948, Air France Laté 631-06 F-BDRC was lost over the Atlantic flying between Fort-de-France, Martinique and Port-Etienne (now Nouadhibou), Mauritania. Wreckage was recovered that indicated an in-flight breakup that possibly involved a fire or explosion, but a definitive cause was never determined. None of the 52 people on board survived. F-BDRC had accumulated 185 flight hours at the time of the accident, and Air France subsequently withdrew its two other Laté 631s from service. Laté 631-04 F-BDRA participated in the search for survivors, flying a total of 75 hours, including a single 26-hour flight.

The flying boat era had ended during the 10 years between when the Latécoère 631 was ordered in 1938, and when the aircraft went into service with Air France in 1947. The advances in aviation during World War II had shown that landplanes were the future of commercial aviation. Following the accidents, there was no hope for the Laté 631 to be used as a commercial airliner. With four completed aircraft and another four under construction, the decision was made to convert the Laté 631 into a cargo aircraft.

Latecoere 631-06 Air France

Laté 631-06 (F-BDRC) made its first flight on 9 November 1947. It was the third (and final) aircraft to be received by Air France. On 1 August 1948, Laté 631-06 disappeared over the Atlantic with the loss of all 52 on board. Air France withdrew its remaining Laté 631 aircraft as a result. Note the access hatch atop the fuselage. Another hatch existed behind the wings.

On 28 November 1948, Laté 631-08 F-BDRE was flown for the first time, taking off from Saint-Nazaire. Laté 631-08 was originally intended as an additional aircraft for Air France but was orphaned after the crash of Laté 631-06. Laté 631-08, along with Laté 631-03, were eventually given to a new company, SEMAF (Société d’Exploitation du Matériel Aéronautique Français / French Aircraft Equipment Exploitation Company). SEMAF was founded in March 1949 and worked to develop the Laté 631 as an air freighter. Laté 631-08 F-BDRE was converted to a cargo aircraft by strengthening its airframe and installing a 9 ft 2 in x 5 ft 3 in (2.80 x 1.60 m) cargo door on the left side of the rear fuselage. The aircraft was first flown with the modifications on 8 June 1949. Laté 631-08 soon began hauling fabric and manufactured products between France and various places in Africa. The aircraft had completed 12 trips by March 1950.

Laté 631-09 F-BDRF preceded Laté 631-08 into the air. Laté 631-09’s first flight occurred on 20 November 1948 at Le Harve. Laté 631-10 F-BDRG made its first flight on 7 October 1949 from Saint-Nazaire. Both of these aircraft were flown to Biscarrosse and stored with the never completed Laté 631-11 F-BDRH. Laté 631-09 and -10 were later reregistered as F-WDRF and F-WDRG.

Laté 631-03 F-BANU was reregistered as F-WANU when it underwent tests to measure vibrations of the airframe and engines. This was done in part to discover what led to the loss of Laté 631-06 F-BDRC. On 28 March 1950, Laté 631-03 made its second flight of the day, taking off from Biscarrosse. With engine power pushed up, the left wing began to flutter, and the outer section of the left aileron broke away. Laté 631-03 began to spin, turned on its back, and continued to spin until it impacted the water inverted. The 12 people on board, which included the crew and engineers from Latécoère and Rotol, were killed instantly. Many witnessed the crash, and the wreckage of Laté 631-03 was recovered. Examination revealed that the engines with a .4375 gear reduction and operating at 1,925 rpm during cruise flight turned the propeller at 840 rpm. This resonated with a critical frequency of the wings, ailerons and Flettner tabs, which was 840 cycles per minute. The interaction rapidly fatigued parts in the outer aileron control system and caused them to fail. The damaged aileron system allowed the aileron to flutter, breaking the control system completely and leading to a complete loss of aircraft control.

Latecoere 631-08

Laté 631-08 (F-BDRE) is seen here with its updated registration of F-WDRE. Laté 631-08 was the only aircraft that operated as an air freighter.

At the time if the accident, Laté 631-03 had been reengined with R-2600 engines incorporating a .5625 gear reduction. These engines were installed on later Laté 631 aircraft and retrofitted on the earlier aircraft. However, nearly all of the Laté 631-03’s 1,001 hours were with the other engines, which was enough to have fatigued the aileron control to its breaking point. The loss of Laté 631-03 led to the collapse of SEMAF.

With the cause of the crash known, a new company was formed to upgrade the Laté 631 fleet and modify them for cargo service. La Société France Hydro (France Hydro Company) was given charge of Laté 631-02 and Laté 631-08, which was reregistered as F-WDRE. Modifications to prevent a reoccurrence of Laté 631-03’s crash were incorporated into the aircraft, and Laté 631-08 returned to cargo service in late 1951. Laté 631-08 flew a Biscarrosse-Bizerte-Bahrain-Trincomalee-Saigon route of some 7,460 miles (12,000 km) starting in March 1952. The aircraft departed Bizerte, Tunisia with a takeoff weight of 167,000 lb (75,750 kg), the highest recorded for a Laté 631. By 1953, Laté 631-08 was hauling cotton from Douala, Cameroon to Biscarrosse. This had proven somewhat lucrative, and a cargo-conversion of Laté 631-02 was started. Laté 631-05 was also transferred to France Hydro, but little was done with the aircraft. On 10 September 1955, Laté 631-08 broke apart during a violent thunderstorm while over Sambolabo, Cameroon. All 16 people on board were killed. The Latécoère 631 was withdrawn from service after this accident, and no further attempts were made to use the aircraft.

In February 1956, Laté 631-05, -10, and -11 were damaged beyond economical repair when the roof of the Biscarrosse hangar collapsed after heavy snowfall. All of the remaining Latécoère 631s were subsequently scrapped, most in late 1956. In 1961, the remains of Laté 631-01 and the SE.200 prototype were raised from Lake Constance by a Swiss recovery team and subsequently scrapped.

Latecoere 631-08 France-Hydro

Laté 631-08 while in service with France Hydro. The aircraft crashed in a storm on 10 September 1955; this was the last flight of any Laté 631. The remaining aircraft were later scrapped. Note the open door on the bow and the open hatch forward of the cockpit that led to a cargo hold.

Sources:
Les Paquebots Volants by Gérard Bousquet (2006)
Latécoère: Les avions et hydravios by Jean Cuny (1992)
https://aviation-safety.net/database/types/Latecoere-631/database
https://www.baaa-acro.com/crash-archives?field_crash_aircraft_target_id=Lat%C3%A9co%C3%A8re%20631%20(29691)

Piaggio P119 engine

Piaggio P.119 Experimental Fighter

By William Pearce

Founded in 1884, Piaggio was an Italian industrial firm that began making aircraft under license in 1917. In 1923, Piaggio began building aircraft of its own design, led by Giovanni Pena. In the early 1930s, Piaggio began to manufacture aircraft engines under license. In 1936, Pena left the company and was replaced by Giovanni Casiraghi. Casiraghi had previously worked for the Waco Aircraft Company in the United States for several years.

Piaggio P119 mockup

Mockup of the Piaggio P.119 in the Finale Ligure plant. Note the guns in the wing. They appear to be 7.7 mm (.303-cal), but it is not clear. Only two machine guns are in the nose.

In 1938, Casiraghi began to design a new single-seat fighter of a rather unconventional configuration. He aspired to create a fast and maneuverable fighter that utilized as many Piaggio-sourced components as possible—the aircraft, engine, and propeller were all manufactured by Piaggio. Designated as the Piaggio P.119, the fighter design was submitted to the Regia Aeronautica (Italian Royal Air Force) on 18 March 1939. While the Regia Aeronautica was busy with other projects, Casiraghi continued to refine the fighter. The experimental P.119 was not ordered until 2 June 1941.

The P.119 had a conventional layout with the exception of the engine installation. The air-cooled, radial engine was located in the fuselage, behind the pilot. An extension shaft extended from the engine, under the cockpit, and to the propeller gear reduction at the front of the aircraft. This configuration provided good pilot visibility and enabled the armament to be centrally located in the aircraft’s nose and the engine to be located at the aircraft’s center of gravity, which enhanced maneuverability.

Piaggio P119 construction

The P.119 under construction at Finale Ligure. Note the tubular-steel center section of the engine mount and the frame of the aileron awaiting its fabric covering.

The P.119 had an all-metal airframe made up of three sections. The front and rear fuselage sections had an aluminum frame covered with aluminum panels, creating a monocoque structure. The center section, which supported the engine and wings, consisted of a tubular steel frame covered with aluminum panels. The entire fuselage possessed a circular cross section. Under the conventional tail was a non-retractable tailwheel. The all-metal wings had two spars and housed the fully retractable main wheels. Large ailerons occupied the outer half of the wings’ trailing edge, with split-flaps running along the remaining trailing edge of the wing. All control surfaces had an aluminum frame and were covered with fabric. Each wing contained an 87-gallon (330 L) fuel tank, and a 90-gallon (340 L) fuel tank was located in the fuselage behind the engine.

The cockpit was placed above the wings’ leading edge and covered with a canopy that hinged to the side (some sources state the canopy slid back). However, it does not appear that the hinged canopy covering was installed. Behind the cockpit was a tubular-steel frame that supported the air-cooled radial engine and connected the aircraft’s nose section, wings, and tail section. Originally, a 1,700 hp (1,268 kW) Piaggio P.XXII engine was to be used, but delays with that engine resulted in the substitution of a 1,500 hp (1,119 kW) Piaggio P.XV. Both engines had 18 cylinders and displaced 3,237 cu in (53.0 L). A scoop located under the aircraft’s nose brought in cooling air that was distributed annularly into the cooling fins of the engine’s cylinders with baffles helping to direct the airflow. The cooling-air exited via a semi-annular line of cowl flaps set atop the fuselage. Just behind the cockpit was the engine’s intake, and the exhaust was expelled from four stacks forward of the cowl flaps. The P.119’s variable-pitch, three-blade propeller was made by Piaggio and was 10 ft 10 in (3.3 m) in diameter.

Piaggio P119 engine

Nicolò Lana in the cockpit of the P.119 preparing for an engine run. The canopy has been removed, and only two machine guns are installed in the nose. The two left-side exhaust stack openings are visible in front of the open cowl flaps.

The aircraft’s armament consisted of four 12.7 mm (.50-cal) machine guns positioned in the nose above the propeller gear reduction and a 20 mm cannon that fired through the propeller hub. The machine guns had 500–550 rpg (the number varies by source), and the 20 mm cannon had 110 rounds. Some sources state that provisions existed to install two additional machine guns in each wing with 400 rpg. However, those sources disagree on whether the guns were 7.7 mm (.303-cal) or 12.7 mm (.50-cal). A mockup of the P.119 included the wing guns, which appear to be 7.7 mm (.303-cal), but the mockup also appears to have only two nose machine guns. Images of the P.119 prototype do not indicate any provisions for wing guns. Reportedly, the prototype did not have the cannon or two of the four nose machine guns installed. Consideration was given to a ground attack version with a 37 mm cannon firing through the propeller hub, and a bomb rack under each wing and under the aircraft’s centerline.

Piaggio P119 rear

Rear view of the P.119 illustrates the aircraft’s relatively clean exterior. The aircraft is at Villanova d’Albenga, presumably before its first flight.

The Piaggio P.119 had a wingspan of 42 ft 8 in (13.0 m), a length of 31 ft 10 in (9.7 m), and a height of 9 ft 10 in (3.0 m). The aircraft had a top speed of 398 mph (640 km/h) at 22,310 ft (6,800 m) and a stalling speed of 81 mph (130 km/h). The P.119 had an empty weight of 5,886 lb (2,670 kg) and a maximum weight of 9,039 lb (4,100 kg). The aircraft had an initial rate of climb of approximately 3,077 fpm (15.6 m/s), and a climb to 19,685 ft (6,000 m) took 7 minutes and 15 seconds. The P.119’s ceiling was 41,011 ft (12,500 m), and it had a maximum range of 932 miles (1,500 km).

Some sources indicate that two P.119 prototypes were ordered and given the Matricola Militare (military registration number) of MM 496 and MM 497, with MM 496 used on the mockup and MM 497 applied to the actual prototype. It is not clear why a mockup would need a serial number, and other sources contend that MM 496 was assigned to the prototype. However, MM 496 appears to have been assigned to the Piaggio P.108C prototype four-engine transport, and the majority of sources state that MM 497 was the P.119 prototype.

Piaggio P119 painted

The P.119 undergoing an engine run. Note the scoop that brought in cooling air for the engine. The aircraft had a fairly wide-track landing gear.

The P.119 was built at Piaggio’s Finale Ligure plant in western Italy. The aircraft was completed in late 1942 and underwent ground tests in mid-November. The P.119’s first flight occurred on 19 December 1942. The aircraft was flown at Villanova d’Albenga by Nicolò Lana. The initial flight testing revealed that the P.119 suffered from engine cooling issues, requiring the cowl flaps to stay open. The open flaps slowed the aircraft and caused its nose to pitch up. Other issues included vibrations from the engine and extension shaft installation and general instability of the P.119. These issues resulted in complete flight trails not being conducted, and aerobatic maneuvers were not attempted. On 2 August 1943, the P.119 was damaged when the brakes locked up on landing, causing the aircraft to nose over. The damage was minor and mostly limited to the propeller and a wing, but the aircraft was not repaired before the Italian surrender on 8 September 1943. Problematic and difficult to fly, the P.119 subsequently disappeared and was presumably scrapped.

Piaggio P119 noseover

The P.119 after it nosed over during landing on 2 August 1943. While the aircraft has been painted, it does not appear that the canopy cover has been installed. Note the deployed split flaps, and the intake scoop behind the cockpit.

Sources:
Dimensione Cielo 3: Caccia Assalto by Emilio Brotzu, Michele Caso, Gherardo Cosolo (1972)
Volare Avanti: The History of Piaggio Aircraft by Paolo Gavazzi (2000)
War Planes of the Second World War: Fighters, Volume Two by William Green (1961)
Italian Civil and Military Aircraft 1930-1945 by Jonathan Thompson (1963)
https://web.archive.org/web/20161121220013/http://italie1935-45.com/regia-aeronautica/appareils/item/323-piaggio-p-119
https://ww2aircraft.net/forum/threads/piaggio-p-119.47582/

Lun MD-160 Ekranoplan cruiser

Lun-class / Spasatel Ekranoplans

By William Pearce

In March 1980, the Soviet government envisioned a fast-attack force utilizing missile-carrying ekranoplans. An ekranoplan (meaning “screen plane”), also known as wing-in-ground effect (WIG) or ground-effect-vehicle (GEV), is a form of aircraft that operates in ground effect for added lift. The machines typically operate over water because of their need for large flat surfaces.

Lun MD-160 Ekranoplan moored

The missile-carrying Lun ekranoplan at rest on the Caspian Sea. The craft exhibits worn paint in the undated photo. Note the gunner’s station just below the first missile launcher. A Mil Mi-14 helicopter is in the background.

When the missile-carrying ekranoplan was being considered, the huge KM (Korabl Maket) ekranoplan was being tested, and testing was just starting on the three production A-90 Orlyonok transport ekranoplans. Known as Project 903, the missile-carrying Lun-class ekranoplans would be built upon the lessons learned from the earlier machines. The word “lun” (лунь) is Russian for “harrier.” An order for four examples was initially considered, with the number soon jumping to 10 Lun-class machines.

The first Lun-class ekranoplan was designated S-31, with some sources stating the designation MD-160 was also applied. Most sources referred the craft simply as “Lun.” The Lun was designed by Vladimir Kirillovykh at the Alekseyev Central Hydrofoil Design Bureau in Gorky (now Nizhny Novgorod), Russia. The new craft differed from previous ekranoplans by not having dedicated cruise engines.

Lun MD-160 Ekranoplan at speed

The Lun at speed traveling over the water’s surface. Note the contoured, heat-resistant surface behind each missile tube to deflect the exhaust of the launching missile. The large domes on the tail are evident in this image.

The Lun’s all-metal fuselage closely resembled that of a flying boat with a stepped hull. Mounted just behind the cockpit were eight Kuznetsov NK-87 turbojets, each capable of 28,660 lbf (127.5 kN) of thrust. The engines were mounted in sets of four on each side of the Lun. The nozzle of each jet engine rotated down during takeoff to increase the air pressure under the Lun’s wings (power augmented ram thrust). This helped the craft rise from the water’s surface and into ground effect. The nozzles were positioned straight back for cruise flight.

Lun MD-160 Ekranoplan ship

With flaps down, the Lun passes by a Soviet Navy ship. The rear gunner’s position is just visible at the rear of the craft.

The mid-mounted, short span wings had a wide cord and an aspect ratio of 3.0. Six large flaps made up the trailing edge of each wing, with the outer flaps most likely operating as flaperons (a combination flap and aileron). The tip of each wing was capped by a flat plate that extended down to form a float. A single hydro-ski was positioned under the fuselage, where the wings joined. The hydraulically-actuated ski helped lift the craft out of the water as it picked up speed. A swept T-tail with a split rudder at its trailing edge rose from the rear of the fuselage. Radomes in the tail’s leading edge housed equipment for navigational and combat electronics. The large, swept horizontal stabilizer had large elevators mounted to its trailing edges.

Lun MD-160 Ekranoplan cruiser

Looking more like an alien ship out of a science fiction movie than a cold-war experiment, the Lun was an impressive sight. Note the chines on the bow to help deflect water from the engines.

Mounted atop the Lun were three pairs of angled missile launchers. No cruise engines were mounted to the Lun’s tail over concerns that the engines would cut out when they ingested the exhaust plume from a missile launch. The launchers carried the P-270 (3M80) Moskit—a supersonic, ramjet-powered, anti-ship cruise missile. The P-270 traveled at 1,200 mph (1,930 km/h) and had a range of up to 75 miles (120 km). The belief was that the Lun-class ekranoplans would be able to close in on an enemy ship undetected and launch the P-270 missile, which would be nearly unstoppable to the enemy ships. The Lun also had two turrets, each with two 23 mm cannons. One turret was forward-facing and positioned below the first pair of missile launchers. The second turret was rear-facing and positioned behind the Lun’s tail.

Lun MD-160 Ekranoplan Kaspiysk

View of the Lun in March 2009 as it sits slowly deteriorating at the Kaspiysk base on the Caspian Sea. The special dock was made for the Lun. The dock was towed out to sea and submerged to allow the Lun to either float free for launch or be recovered.

The Lun had a wingspan of 144 ft 4 in (44.0 m), a length of 242 ft 2 in (73.8 m), and a height of 62 ft 11 in (19.2 m). The craft had a cruise speed of 280 mph (450 km/h) and a maximum speed of 342 mph (550 km/h). Operating height was from 3 to 16 ft (1 to 5 m), and the Lun had an empty weight of 535,723 lb (243,000 kg) and a maximum weight of 837,756 lb (380,000 kg). The craft had a range of 1,243 miles (2,000 km) and could operate in seas with 9.8 ft (3 m) waves. The Lun had a crew of 15 and could stay at sea for up to five days.

The Lun was launched on the Volga River on 16 July 1986. Operating from the base at Kaspiysk, Russia, testing occurred on the Caspian Sea from 30 October 1989 to 26 December. By that time, plans for the Lun-class of missile-carrying ekranoplans had faded, and the decision was made that only one of the type would be built. The Lun was withdrawn from service sometime in the 1990s and stored at Kaspiysk, where it remains today. In 2002, there was talk of reviving the missile-carrying ekranoplan, but no action was taken.

Lun MD-160 Ekranoplan Kaspiysk igor113

An interesting view of the Lun sitting at Kaspiysk in late-2009. Note the downward angle of the jet nozzles, and the flaps appear to be disconnected. The elements have taken a toll on the ekranoplan. (igor113 image)

The second machine (S-33), which was about 75-percent complete, was converted to serve as a Search and Rescue (SAR) craft. This decision was in part due to the loss of the K-278 Komsomolets submarine on 7 April 1989. A fire caused the loss of the submarine, and 42 of the 69-man crew died, many from hypothermia as they awaited rescue. This accident illustrated the need for a fast-response SAR craft.

Spasatel Ekranoplan Volga

The Spasatel in mid-2014 at the Volga Shipyard with a protective wrap to help preserve the craft. The wings and horizontal stabilizers are resting on the ekranoplan’s back. Note the machine’s reinforced spine. (rapidfixer image)

For its new purpose, S-33 was named Spasatel for “Rescuer.” Conversion work was started around 1992. The Spasatel had the same basic configuration as the Lun but had a reinforced spine and an observation deck placed atop its tail. The Spasatel possessed the same dimensions and performance as the Lun. However, sources state that the Spasatel would fly out of ground effect. For sea search missions, the craft would fly at an altitude of 1,640 ft (500 m), and it had a ceiling of 24,606 ft (7,500 m). The Spasatel had a range of 1,864 miles (3,000 km).

Spasatel Ekranoplan Volga Andrey Orekhov

The Spasatel seen in late 2018 at the Volga / Krasnoye Sormovo Shipyard in Nizhny Novgorod. The craft has been outside and exposed to the elements since 2016. Note the observation deck incorporated into the tail. (Андрей Орехов / Andrey Orekhov image)

The SAR ekranoplan would be quickly altered based on its mission. The Spasatel could carry up to 500 passengers, or temporarily hold 800 people for up to five days waiting for rescue. As a hospital ship, 80 patients could be treated on the Spasatel. A tank with 44,092 lb (20,000 kg) of fire retardant could be mounted atop the Spasatel for fighting fires on ships or oil platforms. Or, a submersible with space for 24 people could be mounted on the Spasatel for responding to submarine accidents. The Spasatel could even respond to oil spills and lay out 9,843 ft (3,000 m) of barriers. Even more ambitious was the noble plan to have several Spasatel ekranoplans in-service around the world ready to respond to any call of marine distress at a moment’s notice.

The Spasatel was about 80-percent complete when work was halted in the mid-1990s due to a lack of funds. In 2001, there was renewed hope that the Spasatel would be completed, but again, no money was forthcoming. The Spasatel was housed in the construction building at the Volga Shipyard until 2016, when it was moved outside. In 2017, there was again some hope that the Spasatel would be completed, now for SAR missions in the Arctic. Under this plan, work on the Spasatel would continue from 2018 until its completion around 2025. However, it does not appear that any work has been done, and the Spasatel continues to deteriorated as it sits exposed to the elements.

Spasatel Ekranoplan Model

Spasatel model from 2017 depicting its new purpose as an artic rescue craft. It does not appear that any work has been performed on the actual machine, but who knows what the future may hold. (Valery Matytsin/TASS image via The Drive)

Sources:
Soviet and Russian Ekranoplans by Sergy Komissarov and Yefim Gordon (2010)
WIG Craft and Ekranoplan by Liang Lu, Alan Bliault, and Johnny Doo (2010)
https://s1rus.livejournal.com/154716.html
https://www.thedrive.com/the-war-zone/15542/russia-supposedly-bringing-back-giant-ekranoplans-for-arctic-missions
http://iiaat.guap.ru/?n=main&p=pres_spasatel
https://en.wikipedia.org/wiki/Spasatel
https://igor113.livejournal.com/51213.html
https://igor113.livejournal.com/52174.html
https://igor113.livejournal.com/52878.html

Alexeyev A-90 Orlyonok top

Alexeyev SM-6 and A-90 Orlyonok Ekranoplans

By William Pearce

Rostislav Alexeyev (sometimes spelled Alekeyev) of the Central Hydrofoil Design Bureau (CHDB or Tsentral’noye konstruktorskoye byuro na podvodnykh kryl’yakh / TsKB po SPK) had been working out of the Krasnoye Sormovo Shipyard in Gorky (now Nizhny Novgorod), Russia since the 1940s. In the 1950s, Alexeyev began experimental work with ekranoplans (meaning “screen planes”), also known as wing-in-ground effect (WIG) or ground-effect-vehicle (GEV). His work led to the construction of the massive, experimental KM (Korabl Maket or ship prototype) ekranoplan in the mid-1960s.

Alexeyev SM-6 rear

The SM-6 was a 50-percent scale proof-of-concept vehicle for the A-90 Orlyonok ekranoplan. First flown in 1971, testing of the SM-6 continued until the mid-1980s.

As work on the KM was underway, the Soviet Navy expressed interest in a troop transport ekranoplan, and Alexeyev had started design studies of such a craft as early as 1964. In 1966, the decision was made to construct a 50-percent scale test model of the troop transport. The test ekranoplan was designated SM-6 (samokhodnaya model’-6 or self-propelled model-6).

The SM-6 had a flying boat-style stepped hull that was made of steel and aluminum. The two-place, side-by-side cockpit was near the front of the machine and covered with a large canopy. Two hydro-skis were placed under the hull: one under the nose (bow) and one under the wings. The hydraulically-actuated skis helped lift the craft out of the water as it picked up speed.

Alexeyev SM-6 square

An undated image of the SM-6 on display at Lenin Square in Kaspiysk, Russia. The ekranoplan has since been removed, and its fate is unknown. However, another undated image shows the its derelict fuselage (hull) in a sorry state.

Mounted in the SM-6’s nose were two Milkulin RD-9B jet engines, each of which produced 4,630 lbf (20.6 kN) of thrust. The inlets for the engines were in the upper surface of the nose, and the nozzles protruded out the sides of the SM-6, just behind and below the cockpit. For takeoff, the jet nozzle of each engine was rotated down to increase air pressure under the craft’s wings (power augmented ram thrust). In cruise flight, the nozzles were pointed back for forward thrust.

The low-mounted wing had a short span and a wide cord, and had an aspect ratio of 2.8. Five flaps were attached along each wing’s trailing edge. The outer flaps most likely acted as flaperons, a combination flap and aileron, but definitive proof has not been found. The tip of each wing extended down to form a float. A large vertical stabilizer extended from the rear of the craft. A rudder was positioned on the trailing edge of the vertical stabilizer. When the SM-6 was on the water’s surface, the bottom part of the rudder was submerged and helped steer the craft. Mounted atop the tail was a 3,750 shp (2,796 kW) Ivchenko AI-20K turboprop engine driving a four-blade propeller that was approximately 12 ft (3.65 m) in diameter. Behind the engine and atop the tail was the large horizontal stabilizer with swept leading and trailing edges. Large elevators were incorporated into the trailing edges of the horizontal stabilizer.

Alexeyev A-90 Orlyonok top

The A-90 Orlyonok cruising above the Caspian Sea. The jet intakes positioned atop the bow helped reduce the amount of water ingested into the engines and kept the craft rather streamlined.

The SM-6 had a wingspan of 48 ft 7 in (14.8 m), a length of 101 ft 8 in (31.0 m), and a height of 25 ft 9 in (7.85 m). The craft had a cruise speed of 186 mph (300 km/h) and a maximum speed of 217 mph (350 km/h). Its operating height was from 2 to 5 ft (.5 to 1.5 m), and the SM-6 had a maximum weight of 58,422 lb (26,500 kg). The craft had a range of 435 miles (700 km) and could operate in seas with 3.3 ft (1.0 m) waves.

Construction of the SM-6 started in October 1966 at the Krasnoye Sormovo Shipyard. Insufficient funding caused some delays, and the SM-6 was not finished until 30 December 1970. At that time, the Volga Shipyard was established as an experimental production facility of the CHDB and operated out of the same plant in which the SM-6 was built. The CHDB was also renamed the Alekseyev Central Hydrofoil Design Bureau.

Alexeyev A-90 Orlyonok cargo

The entire front of the Orlyonok swung open to allow access to the cargo hold. A 22,708 lb (10,300 kg) BTR-60PB armored personnel carrier is seen loaded on the Orlyonok. Note the engine’s exhaust nozzle and the machine gun turret.

In July 1971, the SM-6 was transported about 53 miles (85 km) up the Volga River to Chkalovsk, Russia. Initial tests of the craft were conducted in August 1971 on the Gorky Reservoir. In early 1972, the SM-6 was successfully tested on ice and snow. In 1973, modifications were made that included mounting wheels to the hydro-skis. The wheels were used as beaching gear, allowing the SM-6 to power itself out of the water and onto land, or vice versa. Having proven itself as a fully functioning ekranoplan, the SM-6 was transferred to the Kaspiysk base on the Caspian Sea in late 1974. The SM-6 continued to undergo modifications and testing until the mid-1980s. At different points in its career, the SM-6 was marked as 6M79 and 6M80. After it was withdrawn from service, the SM-6 was displayed for a number of years at a public square (Lenin Square?) in Kaspiysk. The elements took a toll on the ekranoplan, and it was eventually removed from the square. The derelict remains of the SM-6 sat near the shore of the Caspian Sea for a time, and mostly likely, the machine was later scrapped.

Following the successful tests of the SM-6 in 1971, plans moved forward for constructing a full-scale, troop transport ekranoplan. The full-size ekranoplan was known as the A-90 Orlyonok (Eaglet) or Project 904. Although twice its size, the Orlyonok had mostly the same configuration as the SM-6.

Alexeyev A-90 Orlyonok front

The Orlyonok’s beaching gear allowed the craft to propel itself out of the water and onto a hard surface. The turning arc of the nose wheel has not been found, but with the main wheels under the wing, the Orlyonok may have been able to turn rather sharply on land.

Mounted in the Orlyonok’s nose (bow) were two Kuznetsov NK-8-4K jet engines that provided 23,149 lbf (103.0 kN) of thrust each. Just behind the craft’s cockpit was a turret with two 12.7-mm (.50-Cal) machine guns. The entire nose of the Orlyonok, including its cockpit, swung open to the right a maximum of 92 degrees. A set of folding ramps allowed for direct entry into the machine’s cargo hold, which was 68 ft 11 in (21.0 m) long, 9 ft 10 in (3.0 m) wide, and 10 ft 6 in (3.2 m) tall. The hold could carry 250 troops or 44,092 lb (20,000 kg) of equipment, including armored vehicles.

The beaching gear mounted to the hydro-skis consisted of a steerable, two-wheel nose unit and a ten-wheel main unit under the hull. The low-mounted wing had a short span and a wide cord, with an aspect ratio of 3.0. The trailing edge of the wing had flaperons at its tips with flaps spanning the rest of the distance. The tip of each wing extended down to form a float. A large vertical stabilizer extended from the rear of the craft. Mounted atop the tail was a 15,000 ehp (11,186 kW) Kuznetsov NK-12MK turboprop engine driving an eight-blade, contra-rotating propeller that was approximately 19 ft 8 in (6.0 m) in diameter. The Orlyonok was equipped with a full-range of navigational and combat electronics.

Alexeyev A-90 Orlyonok slow

At low speed, a fair amount of spray enveloped the Orlyonok. The circular markings on the sides of the craft designated over-wing access doors, which were actually rectangular.

The Orlyonok had a wingspan of 103 ft 4 in (31.5 m), a length of 190 ft 7 in (58.1 m), and a height of 52 ft 2 in (15.9 m). The craft had a cruise speed of 224 mph (360 km/h) and a maximum speed of 249 mph (400 km/h). Operating height was from 2 to 16 ft (.5 to 5.0 m). The Orlyonok had an empty weight of 220,462 lb (100,000 kg) and a maximum weight of 308,647 lb (140,000 kg). The craft had a range of 932 miles (1,500 km) and could operate in seas with 6.6 ft (2.0 m) waves.

The Orlyonok prototype was built at the Volga Shipyard and made its first flight in 1972, taking off from the Volga River. The craft was later disguised as a Tupolev Tu-134 airliner fuselage and transported by barge to the Kaspiysk base on the Caspian Sea for further testing. In 1975, the prototype was accidently beached on a rocky sandbar. The craft was able to power itself back into the water, but the hull was damaged and its structural integrity was compromised. The damage went undetected until the rear fuselage and tail broke off during a landing on rough seas. Alexeyev was onboard and took control of the crippled ekranoplan. Using full-power of the bow jet engines, Alexeyev as able to keep the open back of the hull above water and return to base. The authorities attributed the accident to a design deficiency and blamed Alexeyev, who was removed as the chief designer and reassigned to experimental work.

Alexeyev A-90 Orlyonok GKS-13

The Orlyonok prototype flies past a Soviet Navy ship on the Caspian Sea. Unlike the SM-6, the Orlyonok’s rudder did not extend into the water when the craft was on the sea.

The Russian Navy had been sufficiently impressed by the Orlyonok to order three production machines and a static test article. The damaged prototype was returned to the Volga Shipyard and completely rebuilt as the first production Orlyonok, S-21 (610), which was completed in 1978 and delivered to the Navy on 3 November 1979. The second Orlyonok, S-25 (630), was completed in 1979 and delivered on 27 October 1981. The final Orlyonok, S-26 (650), was completed in 1980 and delivered on 30 December 1981. Plans to produce an additional eight units were ultimately abandoned.

The three Orlyonoks were tested and operated for several years on the Caspian Sea. The captain and crew of S-21 took it upon themselves to test the machine to its limits. Away from witnesses and in the middle of the Caspian Sea, S-21 was flown out of ground effect and up to 328 ft (100 m) for an extended time. At that height, the ekranoplan was sluggish, unstable, and a challenge to fly, but positive control was maintained.

Alexeyev A-90 Orlyonoks

Two production Orlyonoks at Kaspiysk on the Caspian Sea. Note the open over-wing doors and the open engine access panel of the first machine.

By 1989, the three Orlyonoks had performed a total of 438 flights and 118 beachings. On 12 September 1992, S-21 was lost when a control malfunction coupled with pilot error caused it to rise to 130 ft (40 m) and stall. One member of the ten-man crew was killed, and S-21 was eventually sunk by the Navy—the cost of salvaging the craft was too high. Reportedly, the last Orlyonok flight was made by S-26 in late 1993, after which, the Orlyonoks fell into a state of disuse followed by disrepair.

In 1998, the Navy wrote off the two remaining Orlyonoks. Around 2000, S-25 was scrapped, but S-26 was somehow preserved. In 2006, S-26 was given to the Museum and Memorial Complex of the History of the Navy of Russia (Muzeyno-Memorial’nyy Kompleks Istorii Vmf Rossii) located on the Volga River in Moscow. The S-26 was demilitarized in 2007 and restored and installed at the museum in 2008. The Orlyonok design inspired other military and commercial ekranoplan design, but none were built.

Alexeyev A-90 Orlyonok 2008

Orlyonok S-26 shortly after it was put on display at the Naval museum in Moscow. The wheels of the beaching gear are visible, although it appears the main set is missing two wheels. Sadly, the condition of the impressive ekranoplan has deteriorated over the years. (Alex Beltyukov image via Wikimedia Commons)

Sources:
Soviet and Russian Ekranoplans by Sergy Komissarov and Yefim Gordon (2010)
WIG Craft and Ekranoplan by Liang Lu, Alan Bliault, and Johnny Doo (2010)
https://aviationhumor.net/the-last-flight-of-the-soviet-beach-assault-ekranoplan-a-90-orlyonok/#
http://www.volga-shipyard.com/index.php?section=history&lang=eng

Alexeyev KM rear

Alexeyev KM Ekranoplan (Caspian Sea Monster)

By William Pearce

Rostislav Alexeyev (sometimes spelled Alekeyev) was born in Novozybkov, Russia on 18 December 1916. On 1 October 1941, he graduated from the Gorky Industrial Institute (now Gorky Polytechnic Institute) as a shipbuilding engineer. Alexeyev was sent to work at the Krasnoye Sormovo Shipyard in Gorky (now Nizhny Novgorod), Russia. In 1942, Alexeyev was tasked to develop hydrofoils for the Soviet Navy, work that was still in progress at the end of World War II. However, there was sufficient governmental interest for Alexeyev to continue his hydrofoil studies after the war. This work led to the development of the Raketa, Meteor, Kometa, Sputnik, Burevestnik, and Voskhod passenger-carrying hydrofoils spanning from the late 1940s to the late 1970s.

Alexeyev SM-2

The SM-2 was the first ekranoplan that possessed the same basic configuration later used on the KM. The nozzle of the bow (booster) engine is visible on the side of the SM-2. The intake for the rear (cruise) engine is below the vertical stabilizer. Note the three open cockpits.

Alexeyev appreciated the speed of the hydrofoil but realized that much greater speeds could be achieved if the vessel traveled just above the water’s surface. Wings with a short span and a wide cord could be attached to a vessel to lift its hull completely out of the water as it traveled at high speed, allowing it to ride on a cushion of air. Such a craft would take advantage of the ground (screen) effect as air is compressed between the craft and the ground. In Russian, this type of vessel is called an ekranoplan, meaning “screen plane.” They are also known as wing-in-ground effect (WIG) or a ground-effect-vehicle (GEV), since the craft’s wing must stay near the surface and in ground effect. Because ground effect vehicles fly without contacting the surface, they are technically classified as aircraft. However, ground effect vehicles need a flat surface over which to operate and are typically limited to large bodies of water, even though they can traverse very flat expanses of land. Because they operate from water, ground effect vehicles are normally governed by maritime rules.

In the late 1950s, Alexeyev and his team began work on several scale, piloted, test machines to better understand the ekranoplan concept. The first was designated SM-1 (samokhodnaya model’-1 or self-propelled model-1) and made its first flight on 22 July 1961. The SM-1 was powered by a single jet engine and had two sets (mid and rear) of lifting wings. Lessons learned from the SM-1 were incorporated into the SM-2, which was completed in March 1962. The SM-2 had a single main wing and a large horizontal stabilizer. The craft also incorporated a booster jet engine in its nose (bow) to blow air under the main wing to increase lift (power augmented ram thrust). The SM-2 was demonstrated to Premier of the Soviet Union Nikita Khrushchev, who then lent support for further ekranoplan development to Alexeyev and his team.

Alexeyev SM-5

The SM-5 was a 25-percent scale version of the KM. The craft followed the same basic configuration as the SM-2 but was more refined. The structure ahead of the dorsal intake was to deflect sea spray.

Ekranoplan design experimentation was expanded further with the SM-3. The craft had very wide-cord wings and was completed late in 1962. That same year, Alexeyev began working at the Central Hydrofoil Design Bureau (CHDB or Tsentral’noye konstruktorskoye byuro na podvodnykh kryl’yakh / TsKB po SPK). In 1963, the next test machine, the SM-4, demonstrated that a good understanding of ekranoplan design had been achieved. Also in 1963, the Soviet Navy placed an order for a large, experimental ekranoplan transport known as the KM (Korabl Maket or ship prototype).

While the CHDB began design work on the KM, the SM-5 was built in late 1963. The SM-5 was a 25-percent scale model of the KM and was powered by two Mikulin KR7-300 jet engines. The craft had a wingspan of 31 ft 2 in (9.5 m), a length of 59 ft 1 in (18.0 m), and a height of 18 ft 1 in (5.5 m). The SM-5 had a takeoff speed of 87 mph (140 km/h), a cruise speed of 124 mph (200 km/h), and a maximum speed of 143 mph (230 km/h). Its operating height was from 3 to 10 ft (1 to 3 m), and the craft had a maximum weight of 16,094 lb (7,300 kg). The SM-5 could operate in seas with 3.9 ft (1.2 m) waves. Initial tests of the SM-5 were so successful that the decision was made to construct the KM without building a larger scale test machine. Sadly, the SM-5 was destroyed, and its two pilots were killed in a crash on 24 August 1964. During a test, a strong wind was encountered that caused the craft to gain altitude. Rather than reduce power, the pilot added power. The SM-5 rose out of ground effect and stalled.

Alexeyev KM at speed

The KM (Korabl Maket) at speed on the Caspian Sea. Note the “04” tail number and the spray deflectors covering the cruise engine intakes on the vertical stabilizer.

The KM’s all-metal fuselage closely resembled that of a flying boat with a stepped hull. Mounted just behind the cockpit were eight Dobrynin VD-7 turbojets, with four engines mounted in parallel on each side of the KM. Each VD-7 was capable of 28,660 lbf (127.5 kN) of thrust. The jet nozzle of each engine rotated down during takeoff to increase the air pressure under the craft’s wings. These engines were known as boost engines.

The shoulder-mounted, short span wings had a wide cord and an aspect ratio of 2.0. Two large flaps made up the trailing edge of each wing. The tip of each wing was capped by a flat plate that extended down to form a float. Two additional VD-7 turbojets were mounted near the top of the KM’s large vertical stabilizer. These engines were known as cruise engines and were used purely for forward thrust. A heat-resistant panel covered the section of the rudder just behind the cruise engines. At low speeds, the rudder extended into the water and helped steer the KM. Atop the vertical stabilizer was the horizontal stabilizer, which had about 20 degrees of dihedral. A large elevator was mounted to the trailing edge of the horizontal stabilizer.

Alexeyev KM top

The servicemen atop the KM help illustrate the craft’s immense size. Note the access hatches in the wings. This view also shows the ekranoplan’s large control surfaces. The nozzles of the left engines are in the down (boost/takeoff) position while the nozzles on the right are in the straight (cruise flight) position.

The KM had a wingspan of 123 ft 4 in (37.6 m), a length of 319 ft 7 in (97.4 m), and a height of 72 ft 2 in (22.0 m). The craft had a cruise speed of 267 mph (430 km/h) and a maximum speed of 311 mph (500 km/h). Operating height was from 13 to 46 ft (4 to 14 m), and the KM had an empty weight of 529,109 lb (240,000 kg) and a maximum weight of 1,199,313 lb (544,000 kg). The craft had a range of 932 miles (1,500 km) and could operate in seas with 11.5 ft (3.5 m) waves. The KM had a crew of three and could carry 900 troops, but the craft was intended purely for experimental purposes.

The KM was built at the Krasnoye Sormovo Shipyard in Gorky. Alexeyev was the craft’s chief designer and V. Efimov was the lead engineer. The KM was launched on the Volga River on 22 June 1966 and was subsequently floated down the river to the Naval base at Kaspiysk, Russia on the Caspian Sea. To keep the KM hidden during the move, its wings were detached, it was covered, and it was moved only at night. After arriving at the Kaspiysk base, the KM was reassembled, and sea-going trials started on 18 October 1966. V. Loginov was listed as the pilot, but Alexeyev was actually at the controls. At 124 mph (200 km/h), the KM rose to plane on the water’s surface but did not take to the air. Planning tests were continued until 25 October 1966. The early tests revealed that the KM’s hull was not sufficiently rigid and that engine damage was occurring due to water ingestion. Stiffeners were added to the hull, and plans were made to modify the engines.

Alexeyev KM front

While at rest, the KM’s water-tight wings added to the craft’s stability on the water’s surface. Note the far-left engine’s open access panels. Covers are installed in all of the engine intakes.

The first true flight of the KM occurred on 14 August 1967 with Alexeyev at the controls. The flight lasted 50 minutes, and a speed of 280 mph (450 km/h) was reached. Further testing revealed good handling characteristics, and sharp turns were made with the inside wing float touching the water. At one point, the KM was mistakenly flown over a low-lying island for about 1.2 miles (2 km), proving the machine could operate over land, provided it was very flat.

The KM was discovered in satellite imagery by United States intelligence agencies in August 1967. Rather baffled by the craft’s type and intended purpose, the Central Intelligence Agency (CIA) began to refer to the enormous machine as the “Kaspian Monster,” in reference to the KM designation. The “Kaspian Monster” name slowly changed to “Caspian Sea Monster,” which is how the craft is generally known today. The sole KM was painted with at least five different numbers (01, 02, 04, 07, and 08) during its existence. Some sources state the numbers corresponded to different developmental phases, while others contend that the numbers were an attempt to obscure the actual number of machines built.

Alexeyev KM rear

The KM, now with an “07” tail number, cruises above the water. Note the heat resistant panel on the rudder, just behind the exhaust of the cruise jet engines.

While the KM was being built, a second 25-percent scale model was constructed. The model was designated SM-8, and its layout incorporated changes made to the KM’s design that occurred after the SM-5 was built. Like the SM-5, the SM-8 was powered by two Mikulin KR7-300 jet engines. The craft had a wingspan of 31 ft 2 in (9.5 m), a length of 60 ft 8 in (18.5 m), and a height of 18 ft 1 in (5.5 m). The SM-8 had a cruise speed of 137 mph (220 km/h). Operating height was from 3 to 10 ft (1 to 3 m), and the craft had a maximum weight of 16,094 lb (8,100 kg). The SM-8 could operate in seas with 3.9 ft (1.2 m) waves. The craft was first flown in 1968 and tested over a grassy bank in June 1969. The SM-8 also served to train pilots for the KM.

Alexeyev SM-8

The SM-8 was a second 25-percent scale model of the KM and constructed after the loss of SM-5. Its configuration more closely matched that of the KM. The stack above the wings surrounded the intake for the front (booster) engine and deflected sea spray. The front engine was installed so that its exhaust traveled forward to the eight outlets (four on each side) behind the cockpit.

By the late 1960s, the KM had proven that the ekranoplan was a viable means to quickly transport personnel or equipment over large expanses of water. Alexeyev’s focus had moved to another ekranoplan project, the A-90 Orlyonok. By 1979, the KM had been modified by relocating the cruise engines from the vertical stabilizer to a pylon mounted above the cockpit. All engines were fitted with covers to deflect water and prevent the inadvertent ingestion of the occasional unfortunate seabird.

In December 1980, the KM was lost after an accident occurred during takeoff. Excessive elevator was applied and resulted in a relatively high angle of attack. Rather than applying power and correcting the pitch angle, the angle was held and power was reduced. A stall occurred with the KM rolling to the left and impacting the water. The crew escaped unharmed, but the KM was left to slowly sink to the bottom of the Caspian Sea. Reportedly, the craft floated for a week before finally sinking. Either the Soviets were done with the KM, or its immense size prevented reasonable efforts to salvage the machine. From the time it first flew, the KM was the heaviest aircraft in the world until the Antonov An-225 Mriya made its first flight on 21 December 1988. The KM is still the longest aircraft to fly. Experience gained from the KM was applied to the Lun-class S-31 / MD-160.

Alexeyev KM 1979

The KM as seen in 1979 with the cruise engines relocated from the vertical stabilizer to a pylon above the cockpit. A radome is mounted above the engines. All of the engines have been fitted with spray deflectors.

Sources:
Soviet and Russian Ekranoplans by Sergy Komissarov and Yefim Gordon (2010)
WIG Craft and Ekranoplan by Liang Lu, Alan Bliault, and Johnny Doo (2010)
https://en.wikipedia.org/wiki/Rostislav_Alexeyev
https://en.wikipedia.org/wiki/Caspian_Sea_Monster
https://rtd.rt.com/stories/caspian-monster-ekranoplan-vessel/
https://www.theregister.co.uk/2006/09/22/caspian_sea_monster/

Supermarine Spiteful RB518

Supermarine Spiteful and Seafang Fighters

By William Pearce

In 1942, the British Royal Aircraft Establishment at Farnborough and Supermarine Aviation were working on ways to improve the Spitfire fighter. One of the main limiting factors of the aircraft was with its wing encountering compressibility at high speed. The investigation led to interest in designing a laminar flow airfoil and adapting it to an existing Spitfire airframe. In late 1942, the British National Physics Laboratory joined the effort, and Supermarine issued Specification No 470 for the new Spitfire wing in November. As designed, the new wing was 200 lb (91 kg) lighter, would increase the aircraft’s roll rate, and was expected to increase the aircraft’s speed.

Supermarine Spiteful NN660 1st prototype

The first Supermarine Spiteful prototype (NN660) consisted of new laminar flow wings mounted to a Spitfire XIV fuselage. Note the wide and shallow radiator housings under the wings and the standard canopy

A proposal was submitted to the British Air Ministry and gathered enough interest for Specification F.1/43 to be issued in February 1943, calling for a single-seat fighter with a laminar flow wing for Air Force service and provisions for a folding wing to meet Fleet Air Arm (FAA) requirements. Supermarine proceeded with the design under the designation Type 371. Originally, the aircraft was to be named Victor or Valiant, names that were previously (but temporarily) applied to advanced Spitfire models. However, the Type 371 eventually had its name changed to Spiteful. Three prototypes were ordered, and a fourth was added later.

The design of the Supermarine Spiteful was overseen by Joseph Smith. The laminar flow wing was much thinner than the wing used on the Spitfire and necessitated a complete redesign. The all-metal wing had two spars and a straight taper on the leading and trailing edges, which simplified its manufacture. The skin used was relatively thick to add rigidity and improve aileron control. Unlike with the Spitfire, the landing gear retracted inward with the main wheels being housed in the comparatively thick wing roots. The landing gear struts compressed as the gear retracted to minimize the space needed within the wing. Wide and shallow radiators for engine cooling were housed behind the main gear wells. The oil cooler was positioned behind the coolant radiator in the left wing, and the intercooler radiator was positioned in front of the coolant radiator in the right wing. The radiator housings had adjustable inlets and exit flaps. Each wing had two 20 mm cannons with 167 rounds for each inner gun and 145 rounds for each outer gun. The underside of each wing could accommodate two 300 lb (136 kg) rockets or a hardpoint for a drop tank or a bomb up to 1,000 lb (454 kg).

The all-metal, monocoque fuselage of the Spiteful was similar to that of the Spitfire. The cockpit was raised to improve the pilot’s view over the aircraft’s nose. A new, sliding bubble canopy covered the cockpit. Four fuel tanks in the fuselage, forward of the cockpit, held a total of 120 gal (100 Imp gal / 455 L), and a tank in each wing root held 10 gal (8 Imp gal / 36 L). Starting with the third prototype, a 74 gal (62 Imp gal / 282 L) fuel tank was added behind the cockpit, bringing the total internal capacity to 214 gal (178 Imp gal / 809 L). Two 108 gal (90 Imp gal / 409 L) drop tanks could be carried under the wings, or a single 204 gal (170 Imp gal / 773 L) drop tank could be mounted to the aircraft’s centerline.

Supermarine Spiteful NN664 2nd prototype

The Spiteful prototype (NN664) is considered the first true Spiteful because it incorporated the new fuselage. The aircraft was never painted. Note the standard, Spitfire F.21 tail.

The Spiteful’s Mark numbers were a continuation of those used on the Spitfire. The Spiteful F.XIV (F.14) was powered by a 2,375 hp (1,771 kW) Rolls-Royce Griffon 69 with a five-blade, single-rotation propeller. The Spiteful F.XV (F.15) was powered by the 2,350 hp (1,752 kW) Griffon 89 or 90 with a six-blade, contra-rotating propeller. Both Griffon engines had a two-stage, two-speed supercharger, and both the five- and six-blade propellers were 11 ft (3.35 m) in diameter and built by Rotol. Originally, a Rolls-Royce Merlin engine could be substituted for the Griffon if Griffon engine production was found to be lacking, but the Merlin option was dropped in mid-1944.

The Spiteful had a 35 ft (10.67 m) wingspan, was 32 ft 11 in (9.76 m) long, and was 13 ft 5 in (4.10 m) tall. The aircraft had a maximum speed of 409 mph (658 km/h) at sea level, 437 mph (703 km/h) at 5,500 ft (1,676 m), and 483 mph (777 km/h) at 21,000 ft (6,401 m). Cruising speed for maximum range was 250 mph (402 km/h) at 20,000 ft (6,096 m). The Spiteful’s stalling speed was 95 mph (153 km/h). The aircraft’s range was 564 mi (908 km) on internal fuel and 1,315 mi (2,116 km) with drop tanks. The Spiteful had an empty weight of 7,350 lb (3,334 kg), a normal weight of 9,950 lb (4,513 kg), and a maximum weight of 11,400 lb (5,171 kg). The aircraft had an initial rate of climb of 4,890 fpm (24.8 m/s) and a ceiling of 42,000 ft (12,802 m).

Supermarine Spiteful NN667 and RB523 long scoop

A comparison of the third Spiteful prototype (NN667) and the ninth F.XIV production aircraft (RB523). Both have the elongated intake scoop mounted under the engine and just behind the spinner. Note the larger tail compared to the first two Spiteful prototypes.

With other war work taking priority, it was some time before Supermarine had anything related to the Spiteful to test. A mockup was inspected in March 1944, and the aircraft’s name was changed to Spiteful around this time. A set of wings was fitted to a Spitfire XIV (serial number NN660), which became the first Spiteful prototype. The aircraft was first flown on 30 June 1944, with Jeffrey Quill as the pilot. The aircraft used the same 2,035 hp (1,518 kW) Griffon 61 engine as installed in a standard Spitfire XIV, but its performance was superior to that of a standard Spitfire XIV. However, the Spiteful also exhibited rather violent stalling characteristics compared to the fairly docile stall of the Spitfire. This was attributed to the outer wing with the aileron stalling first, which was the opposite of how the Spitfire’s elliptical wing stalled. With the Spitfire, the outer wing stalled last and enabled the ailerons to remain effective deep into the stall. On 13 September 1944, NN660 crashed while engaged in a dog-fight test with a standard Spitfire XIV. The pilot, Frank Furlong, was killed in the crash. A definitive cause was never determined, but it was believed that the aileron control rods became jammed during moderate G maneuvers.

On 8 January 1945, the second Spiteful prototype (NN664) took to the air, piloted by Quill. The aircraft incorporated updated aileron controls and the new Spiteful fuselage. However, NN664 had a tail similar to that used on the Spitfire F.21. Extensive handling tests were undertaken on NN664 that resulted in a few changes. The most significant change was a redesigned tail with its vertical stabilizer and rudder area increased by 28 percent and its horizontal stabilizer and elevator area increased by 27 percent. NN664 first flew with the new tail on 24 June 1945, and the aircraft was sent to the Aeroplane and Armament Experimental Establishment (A&AEE) at RAF Boscombe Down for flight trials.

Supermarine Spiteful RB515 underside

The underside of Spiteful RB515, the first production aircraft, illustrates the wings’ straight leading and trailing edges. Note the standard, short intake scoop. Outlines of the radiator housing doors are visible.

Shortly after NN664’s first flight, the Air Ministry ordered 650 Spiteful aircraft. The order went through a number of reductions, including the cancellation of 150 Spitefuls around 5 May 1945 so that a comparable number of Seafangs (see below) could be ordered. The fourth prototype was included in these cancellations.

The third Spiteful prototype (NN667) was sent to the A&AEE for service evaluations on 1 February 1946. It was found that the aircraft exhibited several areas of poor build quality, and there were numerous concerns with its ease of serviceability. A multitude of fasteners needed to be undone in order to remove the engine cowling, and rearming the aircraft was a time-consuming process that involved disconnecting the controls to the ailerons. A number of modifications and improvements were suggested, but it is not clear just how many were implemented. For at least part of its existence, NN667 had an elongated air intake that would be featured on the Seafang (see below). Other Spitefuls also had the longer scoop (at least RB517, RB518, RB522 and RB523).

The first production Spiteful F.XIV (RB515) made its first flight on 2 April 1945, with Quill in the pilot’s seat. The aircraft originally had an F.21 tail, but a larger Spiteful tail was installed after RB515’s third flight, which ended in a forced landing. The aircraft’s first flight with the new tail was on 21 May 1945. On 27 September 1945, RB515 suffered an engine failure and made another forced landing at Farnborough. The damaged aircraft was subsequently written off.

Supermarine Spiteful RB515 in flight

Another view of RB515 illustrates the larger Spiteful tail that was later applied to the Spitfire F.22 and F.24. The tail improved the Spiteful’s handling, but the aircraft’s stall was still violent compared to the Spitfire’s.

Spiteful RB518 was fitted with a rounded Seafang (see below) windscreen and a 2,420 hp (1,805 kW) Griffon 101 engine to become the sole Spiteful F.XVI (F.16). The Griffon 101 had a two-stage, three-speed supercharger and turned a five-blade, single rotation propeller. In 1947, RB518 achieved 494 mph (795 km/h) at 27,800 ft (8,473 m), the highest level-flight speed recorded by a British piston-powered aircraft. Testing of this aircraft with not-fully-developed engines resulted in seven forced landings—the last was at Chilbolton in March 1949 and resulted in the landing gear being pushed through the wings. The aircraft was then dropped by the recovery crane, ending any hope of repair.

By February 1946, the Spiteful order had been reduced to 80 aircraft. This was again reduced on 22 May 1946 to 22 aircraft, and the Spiteful order finally dropped to 16 aircraft on 16 December 1946. The production order basically covered the aircraft that had been built, although some of the last aircraft may not have flown. A 17th Spiteful, RB520 (the sixth production aircraft), was handed over to the FAA for Seafang (see below) development on 22 September 1945. The aircraft was modified for carrier feasibility trials with a “stinger” arrestor hook incorporated into a special housing below the rudder. RB520 retained the standard, non-folding Spiteful wings.

Supermarine Spiteful RB518

Powered with a two-stage, three-speed Griffon 101 engine, Spiteful RB518 achieved a level-flight speed of 494 mph (795 km/h), the highest recorded by a British piston-powered aircraft. RB518 was the only F.XVI Spiteful and was subsequently written off after its seventh forced landing.

The production aircraft were serialed RB515 to RB525, RB527 to RB531, and RB535. The final Spiteful was delivered on 17 January 1947. Of the three Spiteful prototypes and 17 production aircraft, most were sold for scrap in July 1948. It appears RB518 was the last Spiteful to fly, and no examples of the type survive. The larger “Spiteful tail” was incorporated into the last Spitfires, the F.22 and F.24.

The Spiteful’s cancellation was based on a number of realities including the more impressive performance of jet aircraft, the end of World War II, and serviceability questions about the Spiteful. While the Spiteful’s speed was impressive, it was below the 504 mph (811 km/h) that was originally estimated. Furthermore, the performance of the aircraft’s laminar wing decreased substantially if there were imperfections, including smashed bugs, on the leading edge. It was unlikely that an in-service warplane would be free of all imperfections.

Supermarine Spiteful RB520

Spiteful RB520 was loaned out for Seafang development and is considered by some as a Seafang prototype. Note the tail hook housed below the rudder and the “Royal Navy” stenciling on the fuselage.

Back in October 1943, Supermarine designed the Type 382, which was basically a navalized Spiteful. The design had started with mounting a Spiteful-type, laminar flow wing on a Seafire XV. Little official interest was given to the project until 21 April 1945, when the Air Ministry issued Specification N.5/45 for a single-seat fighter for the FAA. Subsequently, Supermarine was awarded a contract for two prototype Type 382 fighters, which became the Seafang. An order for 150 Seafang aircraft was placed on 7 May 1945; this order was essentially a reallocation of Spiteful aircraft that had been cancelled around two days prior.

The production Seafang closely matched the Spiteful but incorporated wings designed so that the last four feet folded vertically. The folding mechanism was hydraulically-powered. The Seafang had an elongated carburetor intake scoop, with the opening just behind the propeller. The aircraft also had a rounded front windscreen rather than the flat plate used on the Spiteful. Under the rudder was a stinger tail hook for catching the arresting cables on the carrier deck. The Seafang’s landing gear was re-enforced to handle carrier operations. The fuel tank behind the cockpit was reduced to 54 gal (45 imp gal / 205 L), resulting in a total internal capacity of 193 gal (161 Imp gal / 732 L).

Supermarine Seafang VG471 front

The first production Supermarine Seafang F.31 (VG471) was essentially a Spiteful with arrestor gear. All F.31 aircraft had standard, non-folding wings. Note what appears to be a wide-cord propeller.

Like the Spiteful, two Seafang variants were planned. The F.31 used the 2,375 hp (1,771 kW) Griffon 69 engine with a five-blade, single-rotation propeller, while the F.32 used the 2,350 hp (1,752 kW) Griffon 89 with a six-blade, contra-rotating propeller. The F.31 was basically a Spiteful with an arrestor hook and did not incorporate folding wings. The F.31s would serve as a test aircraft while the F.32 was being developed.

The Supermarine Seafang had a 35 ft (10.67 m) wingspan, was 34 ft 1 in (10.39 m) long, and was 12 ft 7 in (3.84 m) tall. With wings folded, the span was reduced to 27 ft (8.23 m). The aircraft had a maximum speed of 397 mph (639 km/h) at sea level, 428 mph (689 km/h) at 5,500 ft (1,676 m), and 475 mph (764 km/h) at 21,000 ft (6,401 m). Cruising speed for maximum range was 250 mph (402 km/h) at 20,000 ft (6,096 m). The aircraft’s range was 393 mi (632 km) on internal fuel. The Seafang weighed 8,000 lb (3,629 kg) empty, 10,450 lb (4,740 kg) with a normal load, and 11,900 lb (53,98 kg) maximum. The aircraft had an initial rate of climb of 4,630 fpm (23.5 m/s) and a ceiling of 42,000 ft (12,802 m).

Supermarine Seafang VG471

The side view of Seafang VG471 illustrates many of the aircraft’s features: long intake scoop, straight wing edges, radiator scoop doors, rounded windscreen, bubble canopy, large tail, and arrestor hook.

As previously mentioned, some Spitefuls had the long intake carburetor scoop; RB518 had a Seafang windscreen; and RB520 was fitted with an arrestor hook (resulting in some sources classifying it as a Seafang prototype). This was all done to lead up to Seafang F.31 production aircraft, which were basically Spitefuls with arrestor hooks. The first Seafang F.31 was VG471, which followed the fifth Spiteful off the production line. All of the F.31s had the five-blade propeller, lacked folding wings, and would end up the only production Seafangs that were completed. VG471 was first flown in early January 1946 and used in arrestor hook trials. The original hook installation proved to be weak, and a redesigned system was installed in March 1946. The aircraft passed the trials on 1 May.

The prototype Seafang F.32s were serial numbers VB893 and VB895, and both had contra-rotating propellers and folding wings. VB895 was first flown in early 1946 and was delivered to the A&AEE on 30 June. In August 1946, VB895 was demonstrated separately to the Royal Netherlands Navy, French representatives, and United States representatives in an attempt to sell the Seafang to allies. However, no orders were placed. In May 1947, test pilot Mike Lithgow successfully performed deck trials in VB895 on the HMS Illustrious. The aircraft’s wide track landing gear drastically increased its stability while on the ground, and the contra-rotating propeller eliminated the torque effect. VB895 was also tested with a single, fuselage-mounted 204 gal (170 Imp gal / 773 L) drop tank, and the aircraft was used for armament trials. During a static test firing of the cannons on 18 May 1948, a build-up of gases in the left wing resulted in an explosion that damaged the wing. Extra vents were added, and no further issues occurred.

Supermarine Seafang VB895

The Seafang F.32 prototype VB895 was the first fully-navalized aircraft of the series. The contra-rotating propellers eliminated the torque effect that led to the downfall of many aviators, especially when operating from the short deck of an aircraft carrier.

While praised for its handling and responsiveness, the Seafang did not offer any real advantage over the Seafire 47, and the Seafang’s stall was certainly a disadvantage. An order was subsequently placed for the Seafire. The original interest in the Seafang was based on doubts regarding the suitability of jet aircraft for carrier operations. As those doubts faded, so did interest in the Seafang, and the aircraft was cancelled. A few Seafangs were kept active for a brief time to continue evaluating the laminar flow wing, which was used on the Supermarine Type 392 Attacker. The Attacker was often referred to as a “Jet Spiteful,” although it had Seafang folding wings with the radiators removed and additional fuel tanks installed. The Attacker first flew on 27 July 1946, and it was the first jet fighter to enter operational service with the FAA.

Eighteen production Seafangs were built, carrying serial numbers VG471 to VG490. The first 10 aircraft were F.31s, and the remaining eight were F.32s. However, only the first eight or so aircraft were completed, with the remaining units delivered disassembled. Sadly, like the Spiteful, all of the Seafang examples were scrapped.

Note: The Royal Air Force and Fleet Air Arm used Roman numerals for mark numbers up thorough 1942. From 1943 through 1948, the Roman numerals were phased out for new aircraft, and Arabic numerals were applied. From 1948 onward, Arabic numerals were used exclusively. The Spitefuls were typically referred to using Roman numerals, but the slightly later Seafang used Arabic numerals. The use of both Roman and Arabic numerals in this article refers to the most common use applied for the particular aircraft type.

Supermarine Seafang VB895 wings folded

The folding wings on Seafang VB895 were hydraulically operated and decreased the aircraft’s wingspan by 8 ft (2.4 m). Although, the wide tack landing gear contributed to snaking at low speeds, it enhanced the stability at higher speeds and as the aircraft slammed down on a carrier deck.

Sources:
Spitfire: The History by Eric B. Morgan and Edward Shacklady (2000)
British Experimental Combat Aircraft of World War II by Tony Buttler (2012)
Supermarine Aircraft since 1914 by C.F. Andrews and E.B. Morgan (1981)
Ultimate Spitfires by Peter Caygill (2006)
Supermarine Fighter Aircraft by Victor F. Bingham (2004)
Griffon-Powered Spitfires by Kev Darling (2001)
Fighters: Volume Two by William Green (1961)
Interceptor Fighters for the Royal Air Force 1935–45 by Michael J.F. Bowyer (1984)
Spitfire: A Complete Fighting History by Alfred Price (1992)
Wings of the Weird & Wonderful by Captain Eric Brown (2012)

Fisher P-75A top

Fisher (General Motors) P-75 Eagle Fighter

By William Pearce

Donovan (Don) Reese Berlin had worked as the Chief Engineer for the Curtiss-Wright Corporation. He had designed the company’s successful P-36 Hawk and P-40 Warhawk fighters. Berlin also designed a number of unsuccessful fighters. He left Curtiss-Wright in December 1941 in frustration because he felt the company was not sufficiently supporting his efforts to develop a new fighter. At the request of the US government, Berlin was quickly hired by General Motors (GM) in January 1942 as the Director of Aircraft Development at the Fisher Body Division (Fisher).

Fisher XP-75 43-46950

The Fisher P-75 Eagle was supposed to be quickly and inexpensively developed by utilizing many existing components. However, many resources were expended on the aircraft. The first XP-75 (43-46950) had a uniquely pointed rear canopy. It was also the only example that used a relatively unaltered Douglas A-24 empennage. Note the fixed tailwheel and the fairings that covered the machine gun barrels in the aircraft’s nose.

Fisher was already engaged by the government to build large assembles for the North American B-25 Mitchell bomber, and plans for the manufacture of other aircraft components were in the works. It made sense to have a prominent aeronautical engineer as part of Fisher’s staff. In March 1942, Fisher was tasked to build various components (engine cowlings, outer wing panels, ailerons, flaps, horizontal stabilizers, elevators, vertical stabilizers, rudders) of the Boeing B-29 Superfortress and 200 complete aircraft. A new plant in Cleveland, Ohio would be built to support this order. Beyond Fisher, a number of other GM divisions were involved in building aircraft and aircraft engines under license from other manufacturers. However, GM wanted to design and manufacture its own products to support the war effort. Berlin was a believer in applying automotive methods to produce aircraft, which was a good match for the automotive giant GM.

On 10 September 1942, GM, through Fisher, submitted a proposal to the Army Air Force (AAF) for a new interceptor fighter. The proposal was based on an AAF request from February 1942 for such an aircraft with exceptional performance. The aircraft from Fisher was designed by Berlin, powered by an Allison V-3420 24-cylinder engine, and constructed mainly of components from other aircraft. The aircraft offered impressive performance with a top speed of 440 mph (708 km/h) at 20,000 ft (6,096 m), a 5,600 fpm (28.5 m/s) initial climb rate, a service ceiling of 38,000 ft (11,582 m), and a range of 2,240 miles (3,605 km) with only internal fuel. All of this came with a promise to deliver the first aircraft within six months of the contract being issued.

Fisher XP-75 line

The top image shows at least five XP-75A aircraft under construction. The middle image, from right to left, shows the first two XP-75 aircraft (43-46950 and 43-46951) and the first two XP-75A aircraft (44-32161 and 44-32162). The second XP-75 (second from the right) has the wide H-blade propellers installed, while the other aircraft have the narrow A-blade propellers. The bottom image is a P-75A under construction. Note the V-3420 engine. (Veselenak Photograph Collection / National Museum of the US Air Force images)

Back in February 1941, the Army Air Corps (name changed to AAF in June 1941) had considered the Allison V-3420 as a possible replacement for the Wright R-3350 engine intended for the B-29. The Allison Engineering Company was a division of GM, and at the time, development of the V-3420 was focused on creating the basic engine and not much more. However, the priority of the V-3420 program was scaled-back after the Japanese attacked Pearl Harbor on 7 December 1941.

GM had been searching for an application for its Allison V-3420 engine, and the AAF had tried to entice other manufactures to incorporate the engine in a fighter design. Fisher’s fighter project offered a solution for both entities. The AAF was sufficiently impressed with Fisher’s proposal, and they approved the construction of two prototypes (serials 43-46950 and 43-46951) on 10 October 1942. The aircraft was given the designation P-75 Eagle, with the prototypes labeled XP-75. Some believe the pursuit number “75” was issued specifically at Berlin’s request, as his “Model 75” at Curtiss-Wright became the successful P-36 and led to the P-40. Although there were some reservations with the aircraft’s design, it was believed that a team working under the experienced Berlin would resolve any issues encountered along the way.

Fisher XP-75A long-range side

Aircraft 44-32162 was the fourth of the XP-75-series and the second XP-75A with additional wing fuel tanks. Note the revised canopy and tail compared to the first prototype. The aircraft has narrow A-blade propellers, and the 10-gun armament appears to be installed.

The XP-75 was of all metal construction with fabric-covered control surfaces. The cockpit was positioned near the front of the aircraft and provided the pilot with good forward and downward visibility. The pilot was protected by 177 lb (80 kg) of armor. The cockpit canopy consisted of front and side panels from a P-40. The aircraft’s empennage, with a fixed tailwheel, was from a Douglas A-24 Banshee (AAF version of the Navy SBD Dauntless). Initially, North American P-51 Mustang outer wing panels would attach to the inverted gull wing center section that was integral with the fuselage. However, the P-51 wings were soon replaced by wings from a P-40 attached to a normal center section. The main landing gear was from a Vought F4U Corsair, and it had a wide track of nearly 20 ft (6.10 m). Four .50-cal machine guns were mounted in the aircraft’s nose and supplied with 300 rpg. Each wing carried three additional .50-cal guns with 235 rpg. Under each wing, inside of the main gear, was a hardpoint for mounting up to 500 lb (227 kg) of ordinance or a 110-US gal (416-L) drop tank.

The 2,600 hp (1,939 kW) Allison V-3420-19 engine with a two-stage supercharger was positioned in the fuselage behind the pilot. Each of the engine’s four cylinder banks had an air-cooled exhaust manifold with two exhaust stacks protruding out of the fuselage. Two extension shafts passed under the cockpit and connected the engine to the remote gear reduction box for the Aeroproducts six-blade contra-rotating propeller. Two different types of propellers were used. Initially, a 13 ft (3.96 m) diameter, narrow, A-blade design was used. Many sources state that this propeller was used on the first 12 aircraft. However, some of these aircraft flew with the second design, a 12 ft 7 in (3.84 m) diameter, wide, H-blade. The gear reduction turned the propeller at .407 crankshaft speed.

Fisher XP-75A 44-32161 crash

The empennage (left) and inverted wings and fuselage (right) of XP-75A 44-32161 after its crash on 5 August 1944. An engine explosion and inflight fire led to the empennage separating from the rest of the aircraft. Russell Weeks, the pilot, was able to bail out of the stricken aircraft. (Veselenak Photograph Collection / National Museum of the US Air Force images)

A two-section scoop was located under the fuselage, just behind the wings. The left section held an oil radiator, and coolant radiators were positioned in both the left and right sections. The aircraft’s oil capacity and coolant capacity were 28.5 US gal (108 L) and 31.5 US gal (119 L) respectively. A 485-US gal (1,836-L) fuel tank was positioned in the fuselage between the cockpit and engine. The tank was made of two sections with the extension shafts passing between the sections.

An XP-75 mockup was inspected by the AAF on 8 March 1943. On 6 July, six additional prototypes (serials 44-32161 to 44-32166) were ordered with some design modifications, including changes to the cockpit canopy, the use of a 2,885 hp (2,151 kW) V-3240-23 engine, and additional fuel tanks in each wing with a capacity of 101 US gal (382 L). The extra fuel enabled the P-75 to cover the long-range escort role, something that the AAF was desperately seeking. The long-range fighter prototypes are often referred to as XP-75As, although this does not appear to be an official designation.

Fisher XP-75A assembly

This image shows either 44-32165 or 44-32166 being completed in the Cleveland plant. These two aircraft, the last of the XP-75As, had a bubble canopy, retractable tailwheel, and a new, tall rudder and vertical stabilizer. Note the P-40-style rounded wings. (Veselenak Photograph Collection / National Museum of the US Air Force image)

Since the need for interceptors had faded, many in the AAF were optimistic that the long-range P-75 would be able to escort bombers all the way into Germany and that the aircraft would be able to outperform all German fighters for the foreseeable future. The P-75 also served as insurance if the P-51 and Republic P-47 Thunderbolt could not be developed into long-range escort fighters.

On 8 July 1943, a letter of intent was issued for the purchase of 2,500 P-75A aircraft (serials 44-44549 to 44-47048), but a stipulation allowed for the cancellation of production if the aircraft failed to meet its guaranteed performance. A definitive contract for all of the XP-75 work was signed on 1 October 1943 and stipulated that the first XP-75 prototype would fly by 30 September 1943, and the first long-range XP-75A prototype would fly by December 1943. The first production aircraft was expected in May 1944, and production was forecasted to eventually hit 250 aircraft per month. The production costs for the 2,500 P-75A aircraft was estimated at $325 million.

Fisher XP-75A 44-32165 side

XP-75A 44-32165 with the new (and final) large, angular tail and horizontal stabilizer. However, the aircraft retained the rounded wings. Note the ventral strake behind the belly scoop, and the wide H-blade propellers. The same modifications were applied to 44-32166. The stenciling under the canopy says “Aeroproducts Flight Test Ship No 4.”

The Fisher XP-75A had a wingspan of 49 ft 1 in (14.96 m), a length of 41 ft 4 in (12.60 m), and a height of 14 ft 11 in (4.55 m). The aircraft’s performance estimates were revised to a top speed of 434 mph (698 km/h) at 20,000 ft (6,096 m) and 389 mph (626 km/h) at sea level. Its initial rate of climb was 4,200 fpm (21.3 m/s), with 20,000 ft (6,096 m) being reached in 5.5 minutes, and a service ceiling of 39,000 ft (11,887 m). The aircraft had an empty weight of 11,441 lb (5,190 kg) and a fully loaded weight of 18,665 lb (8,466 kg). With the fuselage tank, a total of 203 US gal (768 L) of fuel in the wings, and a 110-US gal (416-L) drop tank under each wing, the XP-75A had a maximum range of 3,850 miles (6,196 km).

The AAF gave the XP-75 priority over most of Fisher’s other work, particularly that of constructing 200 B-29 bombers. Construction of the first two prototypes was started at Fisher’s plant in Detroit, Michigan. The other six XP-75 aircraft were built at the new plant in Cleveland, Ohio, which opened in 1943. Production of the aircraft would occur at the Cleveland plant.

Fisher P-75A assembly line

The production line with P-75A numbers two through four (44-44550 through 44-44553) under construction. While the aircraft have square wingtips, at least the first one still has the rounded horizontal stabilizer. Note the V-3420 engine by the first aircraft. The wing of an XP-75A is visible on the far right.

Flown by Russell Thaw, the XP-75 prototype (43-46950) made its first flight on 17 November 1943, and it was the first aircraft to fly with the V-3420 engine. Almost immediately the aircraft ran into issues: the center of gravity was off; the ailerons were heavy; the controls were sluggish; the aircraft exhibited poor spin characteristics; and the V-3420 engine was down on power and overheating. The trouble is not very surprising considering the aircraft consisted of parts from other aircraft and was powered by an experimental engine installed in an unconventional manner. The V-3420’s firing order was revised for smoother operation. Modifications to the second prototype (43-46951) included changes to the ailerons and a new rear canopy. The size of the rudder was decreased, but the surface area of the vertical stabilizer was increased by extending its leading edge. The second XP-75 prototype first flew in December 1943.

The first of the six XP-75A long-range aircraft (44-32161) flew in February 1944. The last two of these aircraft, 44-32165 and 44-32166, were finished with a bubble canopy and a new empennage. The new empennage had a retractable tailwheel and a taller vertical stabilizer and rudder. Lateral control was still an issue, and these two aircraft were later modified with larger and more angular vertical and horizonal stabilizers. These changes were also incorporated into most of the P-75A production aircraft.

Fisher P-75A 44-44549

The first production P-75A (44-44549) with its square wingtips and original rounded tail. Note the ventral strake and the fins attached to the horizontal stabilizer. It is not known when the picture was taken (possibly 22 September 1944), but the aircraft and pilot were lost on 10 October 1944.

The third long-range XP-75A aircraft (44-32163) crashed on 8 April 1944, killing the pilot, Hamilton Wagner. The crashed may have been caused by the pilot performing unauthorized aerobatics. On 7 June 1944, the AAF issued the contract for 2,500 P-75A aircraft. Official trials were conducted in June 1944 and indicated that the XP-75A aircraft was well short of its expected performance. A top speed of only 418 mph (673 km/h) was achieved at 21,600 ft (6,584 m), and initial climb rate was only 2,990 fpm (15.2 m/s). However, the engine was reportedly not producing its rated output. On 5 August 1944, XP-75A 44-32161 was lost after an inflight explosion, which separated the empennage from the rest of the aircraft. The pilot, Russell Weeks, successfully bailed out.

In addition to other changes made throughout flight testing of the prototypes, the P-75As incorporated extended square wingtips with enlarged ailerons, the controls were boosted to eliminate the heavy stick forces, and a ventral strake was added that extended between the scoop exit doors and the tailwheel. The P-75A had a wingspan of 49 ft 4 in (15.04 m), a length of 41 ft 5 in (12.62 m), and a height of 15 ft 6 in (4.72 m). The aircraft’s performance estimates were revised down, with a top speed of 404 mph (650 km/h) at 22,000 ft (6,706 m). Its initial rate of climb dropped to 3,450 fpm (17.5 m/s), and the service ceiling decreased to 36,400 ft (11,095 m). The aircraft had an empty weight of 11,255 lb (5,105 kg) and a fully loaded weight of 19,420 lb (8,809 kg).

Fisher P-75A runup

P-75A 44-44550 with the new (and final) square tail and horizontal stabilizer. Note the two-section belly scoop and the F4U main landing gear.

The first two P-75As (44-44549 and 44-44550) were not originally finished with the latest (angular) empennage. Rather, they used the tall, round version that was originally fitted to the last two XP-75A prototypes. A dorsal fillet was later added to the vertical stabilizer. The first Fisher P-75A (44-44549) took flight on 15 September 1944, with the second aircraft (44-44550) following close behind. Aircraft 44-44550 was later altered with the enlarged, square-tipped vertical and horizontal stabilizers, but it is not clear if 44-44549 was also changed. At some point (possibly late September 1944), aircraft 44-44549 had stabilizing fins added to the ends of its horizontal stabilizer. Both aircraft were sent to Eglin Field, Florida for trials. On 10 October 1944, aircraft 44-44549 was lost with its pilot, Harry Bolster. The crash was caused by the propellers becoming fouled by either a nose-gun tube failure or by part of the spinner breaking free. The damaged propellers quickly destroyed the gear reduction, and once depleted of oil, the propeller blades went into a flat pitch. Bolster attempted a forced landing but was not successful.

By the time of the last crash, the AAF had realized it would not need the P-75A aircraft. The P-51B/D and P-47D/N had proven that they were up to the task of being long-range escort fighters, and the war’s end was in sight. The P-75A was larger, heavier, slower, and sluggish compared to fighters already in service. The production contract for the 2,500 P-75As was cancelled on 6 October 1944, and further experimental work was stopped on 8 November. Five P-75A aircraft were completed, with an additional, nearly-complete airframe delivered for spare parts. Construction of approximately 20 other P-75A production aircraft had started, with some assemblies being completed.

Fisher P-75A top

A top view of 44-44550 provides a good illustration of the square wingtips and horizontal stabilizer. The wings were only slightly extended, but the area of the ailerons was increased by a good amount. The square extensions to the horizontal stabilizer increased its area significantly. Note that the machine gun armament is installed.

P-75A 44-44550 was later transferred to Moffett Field, California where it underwent tests on the contra-rotating propellers. The aircraft was scrapped after the tests. In an attempt to produce more power, a new intercooler was installed in 44-44551, and the aircraft was lent to Allison on 28 June 1945. Later, a 3,150 hp V-3420 was installed. Aircraft 44-44552 and 44-44553 were sent to Patterson Field, Ohio and stored for further V-3420 development work. None of the aircraft were extensively flown. The last completed P-75A, 44-44553, was preserved and is currently on display in the National Museum of the US Air Force in Dayton, Ohio. The aircraft went through an extensive restoration in 2008. All other P-75 aircraft were eventually scrapped.

The eight prototype aircraft had cost $9.37 million, and the manufacturing contract, including the six production aircraft, construction of the Cleveland plant, and tooling for production, had cost $40.75 million. This gave a total expenditure of $50.21 million for the 14 P-75 aircraft. In the end, the expeditious and cost-saving measure of combining existing components led to delays and additional costs beyond that of a new design. It turned out that the existing assemblies needed to be redesigned to work together, essentially making the P-75A a new aircraft with new components.

Fisher P-75A side

The pilot under 44-44550’s bubble canopy helps illustrate the aircraft’s rather large size. The P-75’s sluggish handling and lateral instability did not endear the aircraft to test pilots. Note the nearly-wide-open rear shutter of the belly scoop.

An often-cited story states that then Col. Mark E. Bradley, Chief of Aircraft Projects at Wright Field, was so dissatisfied with the XP-75 after making a test flight, that he requested North American add a large fuel tank in the fuselage of the P-51 Mustang. This act led to the ultimate demise of the XP-75 and the ultimate success of the P-51. However, that sequence of events is not entirely accurate.

Bradley initiated North American’s development of the P-51 fuselage tank in July 1943, after evaluating the XP-75’s design. Experiments with the P-51’s 85-gallon (322-L) fuselage tank were successfully conducted in August 1943. In early September 1943, kits to add the tank to existing P-51s were ordered, and about 250 kits arrived in England in November. At the same time, the fuselage tank was incorporated into the P-51 production line. These events preceded the XP-75 prototype’s first flight on 17 November 1943. Bradley’s later flight in the XP-75 solidified his view that the P-51 with the fuselage tank was the best and quickest option for a long-range escort, and that the XP-75, regardless of its progression through development, would not be superior in that role.

Fisher P-75A USAFM

Fisher P-75A 44-44553 has been preserved and is on display in the National Museum of the US Air Force. (US Air Force image)

Sources:
U.S. Experimental & Prototype Aircraft Projects Fighters 1939–1945 by Bill Norton (2008)
Vees For Victory!: The Story of the Allison V-1710 Aircraft Engine 1929-1948 by Dan Whitney (1998)
P-75 Series Airplanes Advance Descriptive Data (20 May 1944)
P-51 Mustang: Development of the Long-Range Escort Fighter by Paul A. Ludwig (2003)
Development of the Long-Range Escort Fighter by USAF Historical Division (1955)
– “Le Fisher XP-75 Eagle” by Alain Pelletier, Le Fana de l’Aviation (August 1996)
– “A Detroit Dream of Mass-Produced Fighter Aircraft: The XP-75 Fiasco” by I. B. Holley, Jr. Technology and Culture Vol. 28, No. 3 (July 1987)
http://usautoindustryworldwartwo.com/Fisher%20Body/fisherbodyaircraft.htm
http://www.alexstoll.com/AircraftOfTheMonth/3-00.html
https://en.wikipedia.org/wiki/List_of_accidents_and_incidents_involving_military_aircraft_(1943%E2%80%931944)
